Aerzen - Turbo G5,Type: AT 400-0.8 T
| Manufacturer | Aerzen |
|---|---|
| Part Number | Turbo G5,Type: AT 400-0.8 T |
| Inner Code | 652765 |
| Description | frequency converter |
| Technical specification | Performance data: frequency converter Medium Air 100% 86.2% Intake volume, handled at intake condition Q1 m³/min 120 103.5 Intake volume, handled at intake condition Q1 m³/h 7200 6207 Volume handled at normal condition reference to T1=273K, p1=1,013 bar, rF=0% QN Nm³/h 6707 5782 Mass flow m kg/h 8669 7474 Density at inlet conditions Rho1 kg/m³ 1.204 1.204 Intake pressure (abs.) p1 bar 1.013 1.013 Outlet pressure (abs.) p2 bar 1.663 1.663 Pressure difference p mbar 650 650 Intake temperature t1 °C 20 20 Discharge temperature t2 °C 82 85 Male rotor speed nHR rpm 23320 23280 Power consumption at coupling Pk kW 151.5 135.8 Unit power Electrical power to the terminal (FC) P2 kW 164.4 147.4 Connection values Discharge piping connection DN 500 Max power (for cable cross-section) Punit kW 358.1 Drawing Tolerances for volume handled at intake % +5 / -5 for power required at the coupling % +5 / -5 Machine noise each unit Sound pressure level with hood approx. Lp(A) dB(A) < 80 Measured in the free field in 1 m distance from the outline of the unit without radiating noise of the pipe (tolerances ± 2 dB(A)), in accordance with DIN EN ISO 2151. Concerning sound development at place of installation please see TN01184 (please ask for if required). |
| Weight | 1750 |
Please contact us to request a price quote for Aerzen - Turbo G5,Type: AT 400-0.8 T, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy Turbo G5,Type: AT 400-0.8 T by Aerzen in United Kingdom?
You can purchase Turbo G5,Type: AT 400-0.8 T by Aerzen from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the Turbo G5,Type: AT 400-0.8 T?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Aerzen in United Kingdom?
While we are not the official distributor or seller of Aerzen in United Kingdom, we source our products from reliable channels and offer you original Aerzen equipment at competitive prices.
How can I access Turbo G5,Type: AT 400-0.8 T catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for Turbo G5,Type: AT 400-0.8 T on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for Turbo G5,Type: AT 400-0.8 T?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
