Alerton - VIP-363-HOA

Manufacturer Alerton
Part Number VIP-363-HOA
Inner Code 4495005
Technical specification

POWER - 20 to 30 VAC @ 50-60
Hz. 50 VA minimum (maximum
100 VA across all BO loads). Half-
Wave rectified. See IMPORTANT
NOTE below.
03 INPUTS - 16-bit universal
Inputs accept 10k thermistor (type
II and III), dry contact, 1k platinum
RTD, 0-20 mA, 0-10 V, or dry
Contact Pulse. External resistor
required for 0-20 mA. Pulse input
Maximum frequency of 100 Hz.
Pulse input minimum duty cycle
5ms ON/ 5ms OFF
POWER OUTPUT FOR
EXTERNAL SENSORS - 20 VDC
± 10% @ 250 mA maximum.
06 BINARY OUTPUTS - SOLID
State relay rated 20-30 VAC @
50/60 Hz, 1.0 amp continuous, 3.5
Amp inrush for 100ms. Hand-off
Auto (H-O-A) switches for manual
override, software controlled,
Monitored switch position status.
See IMPORTANT NOTE below.
03 ANALOG OUTPUTS - 16-bit
Universal analog outputs support

Voltage mode: 0-10 VDC @ 10
mA maximum (1k ohm minimum);
Current Mode: 4-20 mA @ 550
ohms maximum; or binary mode:
12 VDC @ 20 mA maximum relay
Coil current (for controlling low-coil
Current 12 VDC relays and solid
state relays). Hand-off car (H-O-
A) Switches with potentiometers
for manual override, software
Controlled, monitored switch
Position and potentiometer status.
MICROSET - Supports BACtalk®
Microset, Microset II, or Microset 4
On input 0 (IN-0).
INPUT/OUTPUT TERMINATIONS
- Removable header-type screw
terminals.
PRESSURE SENSOR (VIP-363-
VAV) - 16-bit polarity insensitive
Pressure sensor. 0-2 in.w.c. (500
Pa) range 0.0004 in.w.c. (0.1 Pa)
zero-point accuracy. 0.5% span
Repeatability. 1/8-inch x 3/8-inch
long barb fitting. Replaceable field.
MAX DIMENSIONS - 5.32 “(135
mm) W x 4.33” (110 mm) H x 2.26”
(57.4 mm) D
MOUNTING - 35 mm DIN rail or
screw mounting.
ENVIRONMENTAL - Ambient: -20
up to 55°C (-4 to 131°F)/Storage: -
20 to 85°C (-4 to 185°F)/5 to 95%
RH non-condensing.
COMMUNICATIONS - Built-in 4-
Port Gigabit Ethernet Switch
supports 10/100/1000BASE-T.
PROTOCOLS - BACnet/Ethernet,
BACnet/IPv4, BACnet/IPv6, and
Rapid Spanning Tree Protocol
(RSTP).
PROGRAMMING - Supports
Alerton's BD9 DDC file format
Using Alerton's VisualLogic®
set of tools.
REAL TIME CLOCK - 24-HOUR,
365-day, multi-year calendar, with
24-hour power fail backup.
AUTOMATION FEATURES -
Supports 100 trend logs, 100
Alarms, 10 Schedules, and 1 Zone
(internal points only)
MICROPROCESSOR - 32-bit

ARM Cortex-A9 800MHz
MEMORY - 1GB LPDDR3 RAM
and 2GB solid-state disk storage.
I/O MICROCONTROLLER - 32-bit
ARM Cortex-M4F 180MHz
SECURITY - Integrated Secure
Boot prevents loading of tampered
firmware.
INPUT/OUTPUT EXPANSION -
VIP-363-HOA model supports up
To a maximum of eight expansion
I/O modules VXIO-322-HOA and
VXIO-965-HOA. Expansion I/O
Modules connect directly to VIP-
363-HOA or can be remotely
Located up to 3000 feet away from
the VIP-363-HOA. VIP 363-VAV
Does not support the VXIO
modules.
Weight 0.3
