Asco - MC1160016A6DA2
| Manufacturer | Asco |
|---|---|
| Part Number | MC1160016A6DA2 |
| Inner Code | 5143321 |
| Description | PNEUMATIC CYLINDER |
| Technical specification | Main function Pneumatic cylinder Product series / family name Rodless line - MCR Series Sub-range name Magnetically coupled Bore size 16mm bore (B16mm) Stroke length 16" stroke length (S16") Functions Double-acting air/hydro cylinder actuator Design standard magnetic coupl. strength adjustable cushion Pressure 100psi (max. operating pressure) 7bar (max. operating pressure) Temperature -20...60°C ambient temp. -4...140°F ambient temp. Connection type #10-32 UNF threaded pneumatic ports x 2 8 x M5 x .8 threaded mounting holes (carriage) Length 125mm (carriage) 4.92" (carriage) Speed 1m/s (maximum) Net Width (mm) (carriage) 36 mm Material stainless steel housing anodized aluminium end cap; carriage Force 31lbf (100psi working pressure; effective force) 40lbf (breakaway force of magnetic coupl.) 138.8N (7bar working pressure; effective force) 178N (breakaway force of magnetic coupl.) |
| Weight | 2 |
