Ascon - M3-3107-0200

Manufacturer Ascon
Part Number M3-3107-0200
Inner Code 3286797
Description M3 series temperature controller (unconfigured)
Technical specification Item no. M3-3107-0200/9999 A.Nr.: G.Nr.: supply voltage: 85... 265 V~ Output OP1/3: relay (2A/250V normally open contact) Output OP2: relay (2A/250V normally open contact) or logic (0/5VDC, 30mA) not galv. separated adjustable via internal jumpers output OP4: current output 0 (4)... 20 mA 750Ohm/15Vmax galv. separated /500V ~ /1min. Serial interface: without Interface protocol: no Transmitter power: with You can configure freely as follows: Input: PT100; thermocouple L, J, T, K, S; 0 (10)... 50 mV DC, 0 (4)... 20mA over shunt OP1 output: control or alarm output OP2 output: control or alarm output Output OP4: actual or setpoint output Control: ON/OFF or PID, heating or cooling Assignment: 1 output to control and 1 output as alarm o. both outputs as alarm
Weight 0.4

Please contact us to request a price quote for Ascon - M3-3107-0200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy M3-3107-0200 by Ascon in United Kingdom?

You can purchase M3-3107-0200 by Ascon from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the M3-3107-0200?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ascon in United Kingdom?

While we are not the official distributor or seller of Ascon in United Kingdom, we source our products from reliable channels and offer you original Ascon equipment at competitive prices.

How can I access M3-3107-0200 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for M3-3107-0200 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for M3-3107-0200?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
