Badger Meter - MODEL RCDL M25

Manufacturer Badger Meter
Part Number MODEL RCDL M25
Inner Code 364301
Description BADGER METER RCDL DISC METERS POSITIVE DISPLACEMENT – NUTATING DISC
Technical specification (Art.Nr.KT 201602051 RCDL M25 1" PPO Buna Impulsgeber Typ PFT-1E Hallgeber Flüssigkeitsmengenzähler RCDL M25, ohne Aufbau. Werkstoff und technische Daten: Gehäuse : Nylon Meßkammer : Noryl (PPO) O-Ringe : Buna Meßbereich : 1-100 l/min Meßgenauigkeit : +/- 1,5 % vom Wert p-max : 10 bar t-max : 50 °C Anschluß : R 1" Einbaulänge : 190 mm Einbaulage : horizontal, stehend Zolltarif-Nr.: 9028 20 00 Ursprungsland: USA Impulsgeber Typ PFT-1E 604027 Sensor : magnetoresistiv Impulsausgang : Offener Transistor NPN Skalierfaktor : 0.00001 bis 0.9999 Versorgung : 12-24 VDC)
Weight 1

Please contact us to request a price quote for Badger Meter - MODEL RCDL M25, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy MODEL RCDL M25 by Badger Meter in United Kingdom?

You can purchase MODEL RCDL M25 by Badger Meter from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the MODEL RCDL M25?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Badger Meter in United Kingdom?

While we are not the official distributor or seller of Badger Meter in United Kingdom, we source our products from reliable channels and offer you original Badger Meter equipment at competitive prices.

How can I access MODEL RCDL M25 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MODEL RCDL M25 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MODEL RCDL M25?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Badger Meter-MODEL RCDL M25 price
4 / 5
★ ★ ★ ★ ★
(24)
Comments

More products of Badger Meter

  • MN7

    schetchik jidkosti

  • MN80AAP-1

    MN SERİES,70-733 LPM 1200 KPA 3”/80MM BSP

  • RCDL LCR

    Register with pulse output, Electronic counter LCR type with an LCD display and, pulse output above for OG-Baureihe.Anzeige 1: resettable totalizer or flow indication programmable, Format xxxx.x. Display 2: Non-resettable totalizer, 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64 For counter Size: M25-M35-M40-M70-M120-M170 Pulse output: NPN, MOSFET 40V / 2A Pulse factor: 0.01-99.99 Pulse length: 10ms (2ms, 20ms, 40ms) Ext.Stromversorg. : 8-24VDC Pulse output PPL: 0,01-0,1-1-10-100 Dosing control: 0.01 to 999.99 Preliminary circuit: from 0.00 to 99.99 Switching output: NPN, MOSFET 40V / 2A

  • RCDL LCR REGISTER MIT IMPULSAUSGANG U. STROMAUSGANG 4-20MA

    Electronic counter LCR type with an LCD display, Display 1: resettable totalizer or Flow display programmable, Format xxx.xx. Display 2: Non-resettable totalizer 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA

  • RCDL LCR REGISTER OHNE IMPULSAUSGANG

    Electronic counter LCR type with an LCD display, for the OG series Display 1: resettable totalizer or Flow display programmable, format xxxx.x Display 2: Non-resettable totalizer 14 digits Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64

  • RCDL M25

    3/4 "or 1" PPO Viton without pulse, fluid meter RCDL M25 without construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, standing

  • RCDL M25 1"

    Vectra Viton pulse PFT-2 reed contact Liquid meter RCDL M25 without construction. Materials and technical data: Housing: Bronze Measuring chamber: Vectra O-rings: Viton Measuring range: 3-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: ° C Connection: R 1 "outside Installation length: 190 mm Installation position: horizontal, standing 604011 Pulse PFT-2 reed contact about 52 PPL

  • RCDL M25 3/4" ODER 1" PPO VITON OHNE IMPULSGEBER

    (Liquid meter RCDL M25 without Construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, vertical)

  • RCDL M25, WITH PULSE- TRANSMITTER PFT-1E - 52,4 PULSE/LITER SETUP

    Housing : Bronze Chamber : Noryl (PPO) O-Rings : Buna Flowrange : 1-100 l/min Accuracy : +/- 1,5 % of value p-max : 10 bar t-max : 50 °C Connection : Threads 1" male Laylength : 190mm Pulsoutput : Open Collector NPN Scale Factor : 0.00001 to 0.9999 Supply : 12-24 VDC Pulsoutput : S/N : Part-Nr. 141158

  • KT M2000 50

    MID M 2000 mit Flansch DN 50 1.4571

  • 106126

    Oval wheel counter

  • PN : MID M 1000, Type : Typ ModMAG M1000

    magnetic inductive flowmeter

  • 7500P

    Electromagnetic Flow Meter

  • XMT-DS-00738

    Pulse Flow meter

  • P/N: 9008527 Type: MID M 1000 DN 50/16

    Magnetisch-Induktiver-Durchflußmesser

  • 9008563 (MID M 1000)

    Magnetisch-Induktiver-Durchflußmesser

  • 102460 LM OG-PNDA electronic preset counter

    Elektronischer Vorwahlzähler

  • PFT-2 E

    Impulsgeber

  • PTF-1E

    Signal Transmitters
