Baelz - 342-2225, MP342-1511, 373-E07-20-18-5303
| Manufacturer | Baelz |
|---|---|
| Part Number | 342-2225, MP342-1511, 373-E07-20-18-5303 |
| Inner Code | 4608458 |
| Description | valve, completely assembled |
| Technical specification | Best No. 342-2225 1 piece three-way control valve with cooling pipe 5.3103, max. 350°C, stroke 22 mm; without drive 342-2-BK-DN 32-PN 16/25-Kvs 16 Case: GJS-400-18-LT - 5.3103 max. 350°C/17.5 bar - 50°C/25 bar spindle Ø 10 mm DN 32, PN 16/25, Kvs 16 Way of passage: (A-AB) Kvso: 0.004% Corner path: (B-AB) Kvso: 2% max. permiss. max. differential pressure, mixing valves (2 inputs/1 output) 20 bar max. permiss. max. differential pressure diverter valves (1 input/2 outputs) 20 bar Best No. MP342-1511 1 piece hole cone for 342-B/-BK/-BK-SS (in the through way) DN 32, Kvs 10 MP342-LK-DN 32Kvs 10 Best No. 373-E07-20-18-5303 1 piece Digital engine lift drive steadily 2000 N; 18 mm/min; 115 V, 50/60 Hz 373-E07-20-18-S21-MF-FG-5K-7020-115 self-adaptation 1 input signal: 0/2... 10 V or 0/4... 20 mA delivered condition: 0... 10 V 2 output signals: output 1:0... 10 V and output 2:0... 20 mA or Output 1:2... 10 V and output 2:4... 20 mA Delivery condition: 0... 10 V and 0... 20 mA 1 digital input freely adjustable via software 2 relays freely adjustable via DIP switches auxiliary switching contacts 12... 250 VAC Interface: RS 485 Modbus RTU 1 multiple coil potentiometer 5 kOhm incl. drive stand and clutch (S21) for control valves with spindle Ø 10 mm IP 42; stroke max. 22 mm 115 V, 50/60 Hz |
| Weight | 13 |
