Baelz - 342-BK-SS-DN 100-PN 16-Kvs 130
| Manufacturer | Baelz |
|---|---|
| Part Number | 342-BK-SS-DN 100-PN 16-Kvs 130 |
| Inner Code | 3184957 |
| Description | three-way control valve |
| Technical specification | 342-BK-SS without drive Case: GJS-400-18-LT - 5.3103 Internal parts: stainless steel Spindle sealing: stainless steel bellows and safety stuffing box Spindle diameter: 10 mm Nominal pressure: PN 16 Temperature/pressure: max. 350°C/11.2 bar - 50°C/16 bar Medium: thermal oils Through route: (A-AB) Kvso 0.004% Corner path: (B-AB) Kvso 2% Stroke: 22 mm DN 100, Kvs 130 max. permit differential pressure mixing valves (2 inputs/1 output) 2 bar Baelz 342-BK-SS-DN 100-PN 16-kvs 130 Best. - No. 342-062 Motor lift drive for variable mode Baelz 373-E07-20-18-S21... for installation on control valves up to DN 125 with thrust dependent motor limit switches Thrust: 2000 N Control speed Ty: 18 mm/min 50 Hz 21.7 mm/min 60 Hz Protection class: IP 42 Ambient conditions: max. 0... 50°C, 0... 75% r.F. with hand intervention Cover: plastic Stroke: max. 22 mm including aluminum stand (S21), coupling and mounting screws Power supply: 230 V, 50/60 Hz Weight: approx. 2.2 kg Baelz 373-E07-20-18-S21-230 Best. -No. 373-E07-20-18-301 |
| Weight | 40.3 |
Please contact us to request a price quote for Baelz - 342-BK-SS-DN 100-PN 16-Kvs 130, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
