Bailey & Mackey - Type 1381V

Manufacturer Bailey & Mackey
Part Number Type 1381V
Inner Code 499197
Description Pressure Switch
Technical specification Range: 0.2 to 4 bar Adjustable Reset Differential Process Connection: 1/4” BSP male, parallel Wetted parts: 316 Stainless Steel connection with a 316 Stainless Steel diaphragm protection disc Seal: PTFE Switch housing ingress protected to IP65 Electrical Entry: PG 13.5 Conduit Adaptor SPDT microswitch rated 10A @ 250V ac CE marked
Weight 3

Please contact us to request a price quote for Bailey & Mackey - Type 1381V, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy Type 1381V by Bailey & Mackey in United Kingdom?

You can purchase Type 1381V by Bailey & Mackey from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the Type 1381V?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bailey & Mackey in United Kingdom?

While we are not the official distributor or seller of Bailey & Mackey in United Kingdom, we source our products from reliable channels and offer you original Bailey & Mackey equipment at competitive prices.

How can I access Type 1381V catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Type 1381V on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Type 1381V?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Bailey & Mackey-Type 1381V price
5 / 5
★ ★ ★ ★ ★
(6)
Comments

More products of Bailey & Mackey

  • Type 1392P

    Visual Setting Differential Pressure Switch

  • 1392P RANGE:0,1-1BAR

    pressure switch

  • 207 Q (NOT OFFERED REPLACED BY 2381Q)

    Pressure Switch 5 A. 250 V. 207 Q, Rated Current: 5Amp, Ac Nominal Voltage:250Volt,Range: 5-160 PSI,P / Reducer Pve-16D , Serial 69153, 1/2 Npt

  • 207CEQ

    Range: -1 to BAR

  • 3312

    Differential Pressure SwitchRange:

  • 3911/2

    Pressure Switch Range: 1 to 3 bar (Set at 1.4 bar Rising) Process connection: 7/8” BSP Male, 316 Stainless Steel flow through base, with a PTFE/Nitrile bonded diaphragm. Switch Cover Plastic coated

  • 5381

    SWITCH,PRESSURE,ATEX,PRESSURE RANGE 3-14 BAR,DELUGE SYSTEM ZONE #1 TO ZONE #8,SERIES 5000,TYPE 5381,NOTIFICATION NUMBER11044079

  • 92561 016

    Type 1381Q Pressure Switch as serial number 9256{ 0{6 Range: -1 to +1 Overload Protected to 28 bar Process Connection:112" BSP male, parallel Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Switch housing ingress protected to lP65 SPDT microswitch rated 10A @ 250V ac CE marked Stock Code: 52A23

  • D036 - 316

    STLESS STEEL PROTECTION DISC

  • D050P

    PTFE FLAT SEALING GASKET

  • D121

    BERYLLIUM COPPER DIAPHRAGM

  • DIFF.PRESSURE SWITCH 1382

    Pressure range 0,2 - 4bar .

  • K040NUL- M

    SWITCH ASSEMBLED IN BRACKET

  • MODEL 1382

    water flow switch, #0380323003, type SPDT, model 1382, rating 15 amp, 250V range 2-40 psi.

  • REPLACEMENT UNIT FOR PRESSURE SWITCH SERIAL NUMBER 04 86394 003

    (Type 14P Pressure Switch Range: 0.4 to 4 bar Process Connection: 1/8” BSP male, taper Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Electrical Connection: 4-pin plug & socket SPDT microswitch)

  • Type 1381PV

    Pressure switch

  • Type 1381

    Pressure Switch Range: 0.2 – 4 bar Process Connection: 1/4” BSP male, parallel Wetted parts: brass connection with a beryllium copper diaphragm Seal: PTFE Switch housing ingress protected to IP65 SPDT microswitch rated 10A @ 250V ac CE marked

  • Type 1382

    Differential Pressure Switch

  • 1392P

    Pressure Switch

  • TYPE 14

    Pressure Switch Range: 0.4 to 4 bar Process Connection: 1/8” BSP male, taper Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile SPDT microswitch

  • TYPE 2381P

    Twin Circuit Pressure Switch Range: 2 – 28 bar Process Connection: ¾ ”NPT male Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Electrical Entry: 7-pin plug & socket Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac C/W push on crimp connectors CE marked

  • TYPE 2382 / 0484792003

    (Type 2382 Twin Circuit Differential Pressure Switch Range: 0.07 – 1 bar Process Connection: 1/4” BSP female, parallel Wetted parts: brass chambers with a beryllium copper diaphragm Seal: Nitrile Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac Max line pressure 34 bar C/W wall mounting bracket and push on crimp connectors)

  • TYPE 2481

    Pressure Switch

  • Type 3312 Range: 0.07 to 1 Bar

    (Type 3312 Differential Pressure Switch Range: 0.07 to 1 Bar External adjustment and Adjustable Reset Differential. Pressure chambers in 316 Stainless Steel and both connections fitted with 0.5 metres of Stainless Steel clad flexible capillaries connected to remote transmitting diaphragm assemblies System oil filled under vacuum Process connections: 1/4” NPT Female, in UPVC with PTFE transmitting diaphragm protection discs and fitted with 12 hole HALAR (ECTFE) lined mounting rings Seals: PTFE Mounting brackets in polished 316 Stainless Steel fitted to switch and remote transmitters SPDT switch, contact rating 10A at 250V AC Electrical entry: 20mm conduit adapter in 316 Stainless Steel Switch cover in 304 Stainless Steel Max line pressure 11 bar System hydrostatic test: 8 bar for 30 minutes)

  • TYPE 65

    Diaphragm Pressure Gauge

  • type 70

    Pressure Gauge
