Banner Engineering - SLPP25-970
| Manufacturer | Banner Engineering |
|---|---|
| Part Number | SLPP25-970 |
| Inner Code | 761782 |
| Description | Safety light curtain (emitt. + receiv. pair) |
| Technical specification | Defined Area Height Range (mm) >950 - <=1300 Max Operating Range (m) >4 - <=8 Low Profile Yes Primary Housing Material Aluminum Safety Level Type 4 Effective Aperture Angle Type 4 Per IEC 61496-2 Connector Type Removable Disconnect Defined Area Height (mm) 970 Dimensions WxD (mm) 28 x 26 Overall Length (mm) 970 External Monitoring Device 1 or 2 Channel Fixed Blanking Yes Housing Finish Yellow Polyester IP Rating IP65 Operating Distance (m) 0.1 - 7 Operating Voltage 24 V dc +/- 15% Operating Temperature 0 to +55 deg. C; RH 95% PL Rating Ple Recovery Time 33-220 / 109-800 Resolution (mm) 25 Reduced Resolution Yes Response Time 25.5 SIL Rating SIL3; CL3 Electrical Safety Class III Scan Code Selectable Shock 10g at 16ms (6000 cycles) Short Protection Yes System Type Emitter/Receiver Pair Vibration 10-55 Hz at 0.35 mm Auxiliary Output Yes Fault Output Yes Housing Material Aluminum; Zinc; Acrylic OSSD Rating 24 V dc at 0.5 A each Supply Current 210 mA max. Trip/Latch Output Selectable Test Input Yes Feature: End-to-End Sensing Yes |
| Weight | 1 |
Please contact us to request a price quote for Banner Engineering - SLPP25-970, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy SLPP25-970 by Banner Engineering in United Kingdom?
You can purchase SLPP25-970 by Banner Engineering from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the SLPP25-970?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Banner Engineering in United Kingdom?
While we are not the official distributor or seller of Banner Engineering in United Kingdom, we source our products from reliable channels and offer you original Banner Engineering equipment at competitive prices.
How can I access SLPP25-970 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for SLPP25-970 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for SLPP25-970?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
