Boll Kirch - 1.03.2.520.500 DN 250
| Manufacturer | Boll Kirch |
|---|---|
| Part Number | 1.03.2.520.500 DN 250 |
| Inner Code | 1782287 |
| Description | Simplex Filter |
| Technical specification | Filter type : 1.03.2 Housing size : 520.500 Nominal diameter : DN 250 Flange connection according to : DIN 2501 PN 10 with counter flanges Dimension drawing : Z45539 --- OPERATIONAL DATA --- Medium to be filtered : heavy fuel oil Group of fluid in accordance with PED : 1 Max. Flow rate : 100,00 m³/h Operating pressure : 6,00 bar Allowable operating pressure : 10,00 bar Min. allowable operating temperature : 0,00 °C Max. allowable operating temperature : 80,00 °C --- DESIGN/APPROVAL --- Design according to : PED2014/68/EU AD-2000 Vessel volume : 157,00 litre Hydraulic pressure test by : Boll & Kirch with certificate Material certificates : EN 10204/3.2 --- MATERIALS --- Filter housing : ductile cast iron (EN-GJS-400-15) Seals : Viton GF-S --- FILTER ELEMENTS --- Type of filter element : basket element Material of filter element : steel/aluminium Filter mesh made of : stainless steel (1.4401) Mesh no. : 26 Grade of filtration : 800 μm Filtration area : 7000 cm² --- ACCESSORIES --- Differential pressure indicator : 4.36.1 (optical) Setting of DPI : 0 - 0,5 bar Counter flanges with bolts + gaskets : included DPI : with stopcock Drain with ball valve : ja/yes Vent with ball valve : ja/yes lifting lugs : ja/yes filter with cover safety device : ja/yes --- CORROSION PROTECTION --- External painting : Anstrich aussen : 2K-Ep RAL 8007 Internal conservation : Hydraulic oil ISO VG 32 --- MARKING --- Instruction/name plate : English Filter without CE-marking : Marking on filter : GOEGC11AT011 Marking on packing : GOEGC11AT011 --- DOCUMENTATION --- Language of Operating instruction in : English Operating instruction : 1x pdf Inspection certificates : 1x |
| Weight | 350 |
Please contact us to request a price quote for Boll Kirch - 1.03.2.520.500 DN 250 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 1.03.2.520.500 DN 250 by Boll Kirch in United Kingdom?
You can purchase 1.03.2.520.500 DN 250 by Boll Kirch from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 1.03.2.520.500 DN 250 ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Boll Kirch in United Kingdom?
While we are not the official distributor or seller of Boll Kirch in United Kingdom, we source our products from reliable channels and offer you original Boll Kirch equipment at competitive prices.
How can I access 1.03.2.520.500 DN 250 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1.03.2.520.500 DN 250 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1.03.2.520.500 DN 250 ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
