Boll Kirch - 2.04.5.90.145 DN 32 (368375)
| Manufacturer | Boll Kirch |
|---|---|
| Part Number | 2.04.5.90.145 DN 32 (368375) |
| Inner Code | 4265518 |
| Description | Double filter |
| Custom Code | 842123 |
| Technical specification | Filter type: 2.04.5 Case Size (G.Q): 90.145 Connection diameter: DN 32 Flanges to: WN165, square flanges Dimension sheet: Z45540 — OPERATING CONDITIONS — Fluid to be filtered: oil fluid group according to PED: 2 Fluidart according to PED: liquid Maximum flow rate: not specified Operating pressure: not specified Maximum allowable pressure: 16.00 bar Operating temperature: not specified allowance Operating temperature min: 0,00 °C allowance Operating temperature max: 100.00 °C — CONSTRUCTION/ACCEPTANCE — Design and layout: PED2014/68/EU AD-2000 Art. 4, para. 3 Capacity of the container 2:1.00 litres Empty weight: 18 kg Pressure test according to: Boll & Kirch with certificate Material: EN 10204/2.1 — Design Certificates FB-7-80 pressure test 3.1: yes — MATERIALS — Filter housing made of: EN-GJS-400-15 Type of switch valve: Chick tap switching Material of the switch valve: EN-GJS-400-15 Internal parts of the switch valve: EN-GJS-400-15 Lid seals made: Viton Circuit seals off: Viton — FILTER ELEMENTS — Item Type: Basket Sieve Element Material of the element: CrNi steel Cloth of: 1.4401 Tissue number: TELA 5110 Filter fineness: 70 μm Screening area 2x: 222 cm² — ACCESSORIES — Attached differential pressure indicator: 4.36.2 (optic+electrical) Differential pressure gauge sealant: Viton Differential pressure adjustment: cleaning 0.9bar/alarm 1.2bar Opposites. Screws and gaskets: including: square mating flange WN 165, drilled for DN32 — Accessories/Connections — Vent: with plug G1/4" Drain: with plug G3/8" Mating flanges: with flat gasket — Accessories/Differential pressure measurement — DDA: readable from the flange side — Accessories/Other — Magnetic filter insert: yes — CORROSION PROTECTION — Exterior base coat: 2K-Ep RAL 5005 Inner Preservation: Shell Tellus S2 M 32 — LABELLING — Operation/Factory plate: German/English Filters without CE marking |
| Weight | 18 |
Please contact us to request a price quote for Boll Kirch - 2.04.5.90.145 DN 32 (368375), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 2.04.5.90.145 DN 32 (368375) by Boll Kirch in United Kingdom?
You can purchase 2.04.5.90.145 DN 32 (368375) by Boll Kirch from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 2.04.5.90.145 DN 32 (368375)?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Boll Kirch in United Kingdom?
While we are not the official distributor or seller of Boll Kirch in United Kingdom, we source our products from reliable channels and offer you original Boll Kirch equipment at competitive prices.
How can I access 2.04.5.90.145 DN 32 (368375) catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 2.04.5.90.145 DN 32 (368375) on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 2.04.5.90.145 DN 32 (368375)?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
