Boll Kirch - 6.18.3 Gr. 237 DN 80
| Manufacturer | Boll Kirch |
|---|---|
| Part Number | 6.18.3 Gr. 237 DN 80 |
| Inner Code | 4306785 |
| Description | Automatic Filter Type: aquaBoll |
| Technical specification | Filter type : aquaBoll 6.18.3 Size : 237 Nominal diameter : DN 80 Flange connection according to : EN 1092-1/A PN 10 Dimension drawing : similar Z154933 --- OPERATIONAL DATA--- Medium to be filtered : Cooling water Group of fluid in accordance with PED : 2 Category of fluid in accordance with PED : liquid Max. Flow rate : 40,00 m3/h Maximum allowable working pressure : 10,00 bar Operating temperature : 40,00 °С Min. allowable operating temperature : 00,00 °С Max. allowable operating temperature : 60,00 °С Differential pressure : < 0,2 bar at 40,00 m3/h Required Pre-filtration : 10,00 mm --- --- BACK-FLUSHING ------ Back-flushing medium : medium itself Min. operating pressure after filter : 2,00 – 3,00 bar Flushing quantity : 1,1 l/s Flushing time : 30 s Control medium : clean dry air 6,00 bar Motor capacity : 0,090 kW Power supply : 3 ph 400 volt Frequency : 50 Hz Control voltage : 230 volt Control box : 2300 (lose attached) Operating language of control box : English --- DESIGN/APPROVAL --- Design according to : PED2014/68/EU AD-2000 : Article 3, paragraph 3 Vessel volume : 35,00 l Hydraulic pressure test by : Boll & Kirch with certificate --- MATERIALS --- Filter housing : cast iron Internals made of : Stainless steel Seals : Perbunan --- FILTER ELEMENTS --- Type of filter element : filter candle element Qty. of filter elements : 8 Material : Stainless steel Grade of filtration : 80 mkm Total filtration area : 1 840 сm2 --- ACCESSORIES --- Differential pressure indicator : 4.46.2 (optical + electrical) Setting of DPI for back-flushing : 0,35 bar / Alarm 0,50 bar Mud drain valve : pneumatically actuated Nominal diameter of mud drain valve : DN 40 Vent N8 : ball valve Drain N4 : blind flange Backflushing mode : moderate --- CORROSION PROTECTION --- External painting : 2K-Ep RAL 5005 Internal corrosion protection : Boll Epoxy --- MARKING --- Заводская табличка : English --- DOCUMENTATION --- Документация на : English |
| Weight | 270 |
Please contact us to request a price quote for Boll Kirch - 6.18.3 Gr. 237 DN 80, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 6.18.3 Gr. 237 DN 80 by Boll Kirch in United Kingdom?
You can purchase 6.18.3 Gr. 237 DN 80 by Boll Kirch from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 6.18.3 Gr. 237 DN 80?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Boll Kirch in United Kingdom?
While we are not the official distributor or seller of Boll Kirch in United Kingdom, we source our products from reliable channels and offer you original Boll Kirch equipment at competitive prices.
How can I access 6.18.3 Gr. 237 DN 80 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 6.18.3 Gr. 237 DN 80 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 6.18.3 Gr. 237 DN 80?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
