Boll Kirch - P/N: 373154, Type: BFD-P HD 115.280 DN 1
| Manufacturer | Boll Kirch |
|---|---|
| Part Number | P/N: 373154, Type: BFD-P HD 115.280 DN 1 |
| Inner Code | 4434048 |
| Description | double filter |
| Custom Code | 842139 |
| Technical specification | Filter type: BFD-P HD M Case Size (G.Q) :115,280 size: 02 Nominal connection diameter: DN 1" connecting flanges according to: ASME, 300 lbs, RF Dimension sheet: similar to Z138270 fluid to be filtered: ammonia Fluid group according to PED: 1 Fluid type according to PED: gas Max. flow rate: 100.00 Nm³/h Maximum allowable pressure: 40.00 bar (g) perm. Operating temperature min: 0,00 °C perm. Max. operating temperature: 100,00 °C Pressure drop with clean sieves: < 0.1 bar at 100.00 Nm³/h Design and design: ASME VIII Div.1/ped2014/68/EU (without stamp) : Art. 4, para 3 Volume of container 2x: 0.50 litres Pre-check the drawing by: customer Pressure test according to: Boll & Kirch with certificate Material certificates: EN 10204/3.1 — Construction/acceptance — Preliminary inspection documents consisting of: calculation: yes drawings: yes BOM: yes 3-D model step format: yes Earthquake exposure: no Nozzle loads: no wind loads: no — Construction/application — PMI: no NACE: no — Construction/form certificates — Q-plan: FB-8-65 Q-Plan BFD-X gas FB-7-80 pressure test 3.1: min. 1.5 x design FB-7-80 pressure test 3.1: holding time 30 min. FB-7-88 gas pressure test 3.1: min. 1.1 x design Filter housing manufactured from: 316 L/316 Type of changeover valve: ball valve switching Material of diverter valve: 316 L/316 Switching valve internal parts: 316 L Cover seals made of: EPDM Circuit seals off: EPDM Item type: HC1-G VA Material of the element: stainless steel Number of disposable cartridges 2x: 1 Filter fineness: 5 μm Attached differential pressure indicator: without — Accessories/connectors — Vent: with plug 1/2" NPT emptying: with plug 1/2" NPT Differential pressure port: with 1/2" NPT plug — Accessories/nozzle orientation — Admission: 180° Exit: 180° Switch lever: 180° Earthing connection: 0° venting: 0° emptying: 0° wall mount: 0° differential pressure connection: 0° Manufacturer plate: 90°/270° — Accessories/differential pressure measurement — Pressure compensation line with 3 mm aperture: yes — Accessories/others — Grounding tab: yes Wall mount: yes Foot attachment: no Outer primer: WITHOUT Corrosion protection inside: WITHOUT |
| Weight | 70 |
Please contact us to request a price quote for Boll Kirch - P/N: 373154, Type: BFD-P HD 115.280 DN 1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy P/N: 373154, Type: BFD-P HD 115.280 DN 1 by Boll Kirch in United Kingdom?
You can purchase P/N: 373154, Type: BFD-P HD 115.280 DN 1 by Boll Kirch from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the P/N: 373154, Type: BFD-P HD 115.280 DN 1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Boll Kirch in United Kingdom?
While we are not the official distributor or seller of Boll Kirch in United Kingdom, we source our products from reliable channels and offer you original Boll Kirch equipment at competitive prices.
How can I access P/N: 373154, Type: BFD-P HD 115.280 DN 1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for P/N: 373154, Type: BFD-P HD 115.280 DN 1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for P/N: 373154, Type: BFD-P HD 115.280 DN 1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
