Boll Kirch - Typ: 6.21.1 Gr 05 DN 50
| Manufacturer | Boll Kirch |
|---|---|
| Part Number | Typ: 6.21.1 Gr 05 DN 50 |
| Inner Code | 4190033 |
| Technical specification | Commodity code: 842199 Filter type: 6.21.1 Gr: 05 Connection diameter: DN 50 Flanges to: WN165, square flanges Dimension sheet: Z144864 — OPERATING CONDITIONS — Fluid to be filtered: fuel fluid group according to PED: 1 Fluidart according to PED: liquid Maximum allowable pressure: 10.00 bar allowance Operating temperature min: 0,00 °C allowance Operating temperature max: 150.00 °C — BACKWASH Backwash medium: Own medium Flushing volume: 0.20 l/h at 5.00 bar Rinsing time: 1 s Control medium: Air 4-7 bar ISO8573- 1:2010 (7/4/4) Operating voltage: 3 ph 400 volts Frequency: 50 Hz Control voltage: 110 volts Control: Type 2300 (supplied loose) : Z46611, ID 4302300 — CONSTRUCTION/ACCEPTANCE — Design and layout: PED2014/68/EU AD-2000 Art. 4, para. 3 Container volume: 6.00 litres Empty weight: 75 kg Pressure test according to: Boll & Kirch with certificate Material: EN 10204/3.1 — MATERIALS — Filter housing made of: EN-GJS-400-15 Tap chick switch for bypass filter: EN-GJS-400-15 Gasket off: Viton GF-S — FILTER ELEMENTS — Item Type: Multi Segment Element Number of filter elements: 1 Number of filter elements per chamber: 1 no. of filter chambers: 1 Cloth of: 1.4401 Tissue Number: 294/31 Nom. Filter fineness: 20 μm Screening area in operation: 2000 cm² Total screening area: 2000 cm² Sieve insert for bypass filter: Star sieve element Filter fineness bypass filter: 34 μm Screen area bypass filter: 5260 cm² Filtration Absolut Automat: 34 μm Filtration Absolute Bypass: 37 μm — ACCESSORIES — Attached differential pressure indicator: 4.36.2 (optic+electrical) Differential pressure gauge sealant: Viton GF-S Backflushing differential pressure settings: 0.90 bar, alarm 1.20 bar Opposites. Screws and gaskets: included Other accessories: DDA with stopcocks : Filter with lid protection : (BYPASS) — CORROSION PROTECTION — Exterior base coat: 2K-Ep RAL 5005 Inner Preservation: Shell Tellus S2 M 32 — LABELLING — Operation/Factory plate: German/English CE marking according to: - Machinery Directive 2006/42/EC: CE |
| Weight | 75 |
Please contact us to request a price quote for Boll Kirch - Typ: 6.21.1 Gr 05 DN 50, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy Typ: 6.21.1 Gr 05 DN 50 by Boll Kirch in United Kingdom?
You can purchase Typ: 6.21.1 Gr 05 DN 50 by Boll Kirch from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the Typ: 6.21.1 Gr 05 DN 50?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Boll Kirch in United Kingdom?
While we are not the official distributor or seller of Boll Kirch in United Kingdom, we source our products from reliable channels and offer you original Boll Kirch equipment at competitive prices.
How can I access Typ: 6.21.1 Gr 05 DN 50 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for Typ: 6.21.1 Gr 05 DN 50 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for Typ: 6.21.1 Gr 05 DN 50?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
