Burkert - 00338495

Manufacturer Burkert
Part Number 00338495
Inner Code 3409396
Description Prozess-Regelsystem mit Stellungsregler
Custom Code 84818059 / DE
Technical specification 8802-YG-I-A-15,0EE-VA-GM84-M-0-E-H-L-1-0 Typ 8802 Ventiltyp YG - Schrägsitzventil Typ 2300 Ansteuerungstyp I - Positioner 8692 Steuerfunktion A - Mit Federkraft geschlossen Wege/Stellungen 2 - 2 Wege / 2 Stellungen Nennweite 15,0 - 15 mm Dichtwerkstoff EE - PTFE Werkstoff VA - Edelstahl Leitungsanschluss GM84 - G 1/2 Muffe Leitungsanschluss 1 0000 - nicht vorhanden Antriebsausführung G - Element Design Antrieb Antriebsgröße M - DM 70 mm Schnittstelle Arm./Antrieb N1 - Nippelgewinde M28 x 1,5 (Standard DN 13,15) Steuerluftanschluss FA03 - Schnittstelle Element-Ansteuerung und Remote Sensor zu Element Antrieb Flanschbild FA03 - Schnittstelle Element-Ansteuerung und Remote Sensor zu Element-Antrieb Bauform 0 - ohne Funktion 0 - Keine Angabe Pneumatische Funktion E1 - Einfachwirkend DN 0,6 Antriebsart 0 - ohne Ventile Wegsensor 00 - Ohne Versorgungsspannung E - 24V DC Ansteuerung F - 0-10V, 0-5V, 4-20mA, 0-20mA einstellbar Elektr. Anschluss KD - Kabeldurchführung Fluidischer Anschluss GW - G 1/8 / VA Bedienung/Konfig. T - Tastatur und Display intern Näherungsschalter 00 - Ohne Software-Rückmelder H - 1 Binäreingang Zusatzfunktion 0 - Ohne Kommunikation L - Service-büS Anbau 0000 - ohne Bedienung 0 - Nicht vorhanden Ventilblock VB1 00 - Nicht bestückt Steuerfunktion VB1 0 - Keine Angabe Ventilblock VB2 00 - Nicht bestückt Steuerfunktion VB2 0 - Keine Angabe Zulassung System 1 - Mit Zulassung Zubehör 0 - Ohne Zulassung Komponente PL01 - geeignet für die Anwendung mit Lebensmitteln, medienberührte nicht metallische Werkstoffe sind konform zur EG-Verordnung 1935/2004 Zulassung Komponente PU02 - UL listed für USA und Canada cULus
Weight 2.366

Please contact us to request a price quote for Burkert - 00338495, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy 00338495 by Burkert in United Kingdom?

You can purchase 00338495 by Burkert from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the 00338495?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Burkert in United Kingdom?

While we are not the official distributor or seller of Burkert in United Kingdom, we source our products from reliable channels and offer you original Burkert equipment at competitive prices.

How can I access 00338495 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 00338495 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 00338495?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
