Burkert - 237770
| Manufacturer | Burkert |
|---|---|
| Part Number | 237770 |
| Inner Code | 4690050 |
| Description | 2/2-way solenoid valve, force-controlled |
| Custom Code | 84818079 |
| Technical specification | GENERAL INFORMATION --------------------- 2/2-way solenoid valve, force-controlled Article number: 237770 Weight: 0.377 kg Statistical product number: 84818079 MODE OF ACTION ------------- Fluidic line connection number: 2 Valve function Number of switching positions: 2 Valve function: A - closed in rest position - pressure port 1 (P/NC) Manual operation: No PROCESS/LINE CONNECTION ---------------------------- Line connection 1 type: internal thread Line connection 1 Thread name: 1/2 Line connection 1 Thread type: G Line connection 2 type: internal thread Line connection 2 Thread type: G Line connection 2 Thread name: 1/2 TENSION -------- Voltage min/Nominal voltage: 230 V Max. voltage/Nominal voltage: 230 V Voltage frequency: 50 Hz Positive voltage tolerance: 10% Negative voltage tolerance: 10% AC voltage: Yes DC voltage: No Battery Voltage: No MATERIALS ---------- Valve seat material: stainless steel Main valve material in contact with the medium: brass Control of material in contact with medium: PA (polyamide) PRESSURE & TEMPERATURE ------------------ Backpressure-proof version: No Nominal pressure min: 0 bar Max. nominal pressure (liquid): 10 bar Nominal pressure (DIN EN 1333): PN 10 Minimum medium temperature: -10°C Max. medium temperature: 80°C Ambient temperature min: -10 °C Ambient temperature max: 55°C SEALING MATERIAL ----------------- Seat Seal Material Category: Elastomers Seat seal material: NBR (nitrile rubber) Outer sealing Material: NBR (nitrile rubber) Seal pilot material: NBR (nitrile rubber) APPROVALS ----------- Rated power: 8 W NOMINAL SIZE (KV VALUE) ------------------- Kv value (water): 1.9 m3/h Pre-control nominal size (mm): 1.2 mm Main valve size 1 (P) (mm): 10 mm Main valve size 1 (inch): 3/8 inch DEVICE PROPERTIES ------------------- Type: 6213 Drive type: lift anchor Operation: servo-controlled Media separation: No Air flow: via seat Main valve operating principle: diaphragm valve Valve construction: valve complete Switch function: on/off Open switching time min: 10 ms Open switching time max.: 30 ms Close switching time min: 100 ms Close switching time max.: 150 ms Nominal operating mode/duty cycle: 100% Vacuum version: No Analysis version: No Valve setting opening time: No Valve setting closing time: No Oil burner valve: No Steam version: No Central-bolted pilot control: Yes Core guide: slide ring Installation length: 50 mm Main valve with integrated strainer: No ELECTRICAL CONNECTION ---------------------- Electrical connection type: connector diagram form A according to DIN EN 175301-803 Electrical connection Number of contacts: 2 + protective conductor Device outlet included: not included Electrical connection position: left in flow direction DEGREE OF PROTECTION --------- Protection class (IP max. with suitable connection): IP65 COIL (CORE) ------------ Low-noise version: No Spool type: plugged in Spool material (jacket): PA (polyamide) Spool size: 32mm coil circuit surge protection: none Coil circuit rectifier: No Coil circuit pole protection: No Freewheeling diode coil circuit: No Drive thermal insulation class: B Switch-on capacity AC: 24 V·A Rated power AC: 8 V·A Part in contact with the medium Core Material: stainless steel Part in contact with the medium Plug Material: stainless steel |
| Weight | 0.38 |
Please contact us to request a price quote for Burkert - 237770, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 237770 by Burkert in United Kingdom?
You can purchase 237770 by Burkert from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 237770?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Burkert in United Kingdom?
While we are not the official distributor or seller of Burkert in United Kingdom, we source our products from reliable channels and offer you original Burkert equipment at competitive prices.
How can I access 237770 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 237770 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 237770?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
