Burndy - YRB39U34

Manufacturer Burndy
Part Number YRB39U34
Inner Code 1489610
Description Aluminum Compression Reducer Butt Splice
Technical specification
  • Model: YRB39U34
  • Material: Aluminum, tin-plated
  • Conductor Sizes: Barrel A: 700-750 kcmil; Barrel B: 500 kcmil
  • Length: 5.57 inches (141 mm)
  • Outside Diameter: 1.46 inches (37 mm)
  • Strip Length: 2-5/16 inches (59 mm)
  • Color Code: Yellow
  • Die Index: 936
  • Voltage Rating: Up to 35 kV
  • Temperature Rating: 90°C
  • Certifications: UL 486A-486B Listed
  • Features: Dual-rated for aluminum and copper conductors; internal chamfer at wire entry for smooth insertion; pre-filled with PENETROX™ A13 oxide inhibitor; color-coded end caps to prevent foreign material entry; suitable for various industrial applications
  • Applications: Splicing different conductor sizes in electrical installations and maintenance
Weight 1
