Carl Rehfuss - S030HF-V012U-EX-71S/4
| Manufacturer | Carl Rehfuss |
|---|---|
| Part Number | S030HF-V012U-EX-71S/4 |
| Inner Code | 4065876 |
| Description | Belt variable speed gear motor |
| Custom Code | 85015100 |
| Technical specification | 805.05012.00008.0 Design: B6 Swivel position: B Output flange mm: 120 / C Output shaft mm: HW 20 / ext./C Separation speed 1 / min: 7.3 - 36.6 (i = 82) Torque Nm: 32-29 Service factor: 1.0 Painting: RAL 9007 Type of current: 3AC Nominal power kW: 0.25 Operating mode: S1 Nominal voltage V: 230/400 Frequency Hz: 50 Nominal speed 1 / min: 1310 Insulation class: F Protection class IP: 55 KK location: C2 Motor shaft / flange: 14x30 / 105-B14 Gearbox: II2G Ex h IIC T3 Gb Motor: II2G Ex ec IIC T3 Slipping clutch with cover at A (may be set to max 32 NM) Hollow shaft with fastening element Stamp part number 940-77060ATEX on the second nameplate ATEX customer information: Category: 3 Ex atmosphere: G Zone: 2 Temp class for gas: T3 200 ° C Max. Ambient temp. at the place of use: 40 ° C Gearboxes according to EU directive 2014/34 / EU (ATEX) Atex information on the nameplate. Carl Rehfuss Albstadt Year of construction / type year XX / type S030HF-V012U-71S / 4 No./ protection class / design: NR.XXXXXX / IP55 / B6 Lubricant type / quantity: CLP PG ISO VG320 / 0.3 L na max / Ma max / fB: 36.6 rpm / 32 Nm / 1.0 i / ne max / Pe max: 82/3000 rpm / 0.25 kW Ex - marking: II3 G c, k T3 Read the operating instructions before commissioning Recommended lubricant: Tribol 800/320 or 1300/320 All screws secured with Loctite. EX operating instructions enclosed. |
| Weight | 1 |
Please contact us to request a price quote for Carl Rehfuss - S030HF-V012U-EX-71S/4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy S030HF-V012U-EX-71S/4 by Carl Rehfuss in United Kingdom?
You can purchase S030HF-V012U-EX-71S/4 by Carl Rehfuss from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the S030HF-V012U-EX-71S/4?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carl Rehfuss in United Kingdom?
While we are not the official distributor or seller of Carl Rehfuss in United Kingdom, we source our products from reliable channels and offer you original Carl Rehfuss equipment at competitive prices.
How can I access S030HF-V012U-EX-71S/4 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for S030HF-V012U-EX-71S/4 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for S030HF-V012U-EX-71S/4?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
