Carl Rehfuss - S030HF-V012U-EX-71S/4-IE3 / 805.05012.00008.1
| Manufacturer | Carl Rehfuss |
|---|---|
| Part Number | S030HF-V012U-EX-71S/4-IE3 / 805.05012.00008.1 |
| Inner Code | 4535959 |
| Description | Variable variable belt geared motor |
| Custom Code | 85015100 |
| Technical specification | type design Pivot position output flange mm output shaft mm Abtr. speed rpm Torque N.m Operational factor varnishing type of electricity Rated power kW operating mode Rated voltage V frequency Hz Rated speed rpm insulation class Degree of protection IP KK situation Motor shaft/flange : S030HF-V012U-EX-71S/4-IE3 : B6 : B : 120/C : HW 20/ext. /C : 7.3 - 36.6 (i=82) : 32-29 : 1.0 : RAL 9007 : 3AC : 0.25 : S1 : 230/400 : 50 : 1310 : F : 55 : C2 : 14 x 30/105 - B14 Motor in energy efficiency class IE3 Transmission: II2G Ex h IIC T3 Gb Engine: II2G Ex ec IIC T3 Slip clutch with cover at A (may be set to Ma max 32 NM) Hollow shaft with fastening element Stamp on 2nd nameplate part no.940-77060ATEX ATEX customer data: Category: 3 Ex-atmosphere: G zone: 2 Temp.class for gas: T3 200°C max. ambient temperature on site: 40°C Gearboxes according to EU directive 2014/34/EU (ATEX) Atex information on the type plate. Rehfuss Drive Solutions GmbH Build year/type BJ.xx/Type S030HF-V012U-71S/4 No./protection type/design: no. XXXXXXX/ IP55/B6 Lubricant type/quantity: CLP PG ISO VG320/ 0.3 L na max /Ma max/fB: 36.6 rpm /32 Nm/1.0 i/ne max/pe max: 82/3000 rpm/0.25 kW Ex marking: II3 G c, k T3 Observe the operating instructions before commissioning. All screws secured with Loctite. EX operating instructions included. |
| Weight | 30 |
Please contact us to request a price quote for Carl Rehfuss - S030HF-V012U-EX-71S/4-IE3 / 805.05012.00008.1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
