Chromalox - ICON-TD5100

Manufacturer Chromalox
Part Number ICON-TD5100
Inner Code 5128203
Technical specification

1235-05378073

Rated current:
max. 10A internally protected/max. 16A external SiC
Switching capacity:
max. 2600VA internal/max. 3840VA external
Circuit breakers: hybrid relays > 2.5 million cycles
Thermal protection: +85°C (+185°F), manual reverse
Sensor input: Selectable sensor type
Pt100: -99°C to +850°C (-146°F to +1562°F)
Type K: -200°C to +1350°C (-328°F to +2462°F)
Type J: -200°C to +1200°C (-328°F to +2192°F)
For other types, see data sheet
FAT type controller (Fast-Adaptive Tuning)
Setpoint accuracy ±3K
Nominal supply voltage: AC90 to 260V
Optional: limiter function, Delta T, switched off
Functions: Gradient, sequential control, etc.
Display: LCD Graphics:
3 color LEDs to indicate the operating status
Operation: Temperature setting via front display
Optional configuration: via handheld
Signal output: potential-free, dual max. 50mA, 45V
Ambient operating range: -20°C to +50°C (-4°F to +1
Protection class:
IP65 according to IEC 60529 (closed, plug lock
Electrical protection: class I in accordance with IEC 61140
Switch off relay: Switches the heating circuit in case of failure
Case dimensions:
151 x 125 x 60 mm (5.95 x 4.92 x 2.36 inches)

e by type
Case material: PC with clear cover UL94-V0
Weight 0.6
