Coax - CX 519614 MK32 NC

Manufacturer Coax
Part Number CX 519614 MK32 NC
Inner Code 4714678
Description MK 32 NC: 2/2-Way Direct-Acting Coaxial Valve, Normally Closed
Technical specification
  • Model: MK 32 NC
  • Manufacturer: Coax
  • Type: 2/2-Way Direct-Acting Coaxial Valve
  • Function: Normally Closed (NC)
  • Nominal Diameter: DN 32
  • Connection Size: G 1¼" to G 1½" threads or flanges PN 16/40/100
  • Pressure Range: Up to 100 bar
  • Flow Rate (Kv): 20.0 m³/h
  • Media: Suitable for gaseous, liquid, highly viscous, gelatinous, pasty, and contaminated media
  • Flow Direction: A → B as marked
  • Switching Cycles: 150 cycles/min
  • Switching Time: Opening: 440 ms; Closing: 250 ms
  • Media Temperature: -20°C to +100°C (standard); -40°C to +160°C (optional)
  • Ambient Temperature: -20°C to +80°C
  • Weight: Not specified
  • Nominal Voltage: 230 V AC (40-60 Hz); special voltages upon request
  • Actuation: Direct-current magnet with integrated rectifier
  • Protection Class: IP65
  • Energized Duty Rating: 100%
  • Connection: Plug according to DIN EN 175301-803, form A, 4 positions x 90°, wire diameter 6-8 mm
  • Features: Compact design, high-pressure capabilities, optional limit switches and manual override
Weight 10

Please contact us to request a price quote for Coax - CX 519614 MK32 NC, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy CX 519614 MK32 NC by Coax in United Kingdom?

You can purchase CX 519614 MK32 NC by Coax from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the CX 519614 MK32 NC?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Coax in United Kingdom?

While we are not the official distributor or seller of Coax in United Kingdom, we source our products from reliable channels and offer you original Coax equipment at competitive prices.

How can I access CX 519614 MK32 NC catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CX 519614 MK32 NC on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CX 519614 MK32 NC?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Coax-CX 519614 MK32 NC price
