DAYTON - 6Z084
| Manufacturer | DAYTON |
|---|---|
| Part Number | 6Z084 |
| Inner Code | 5088819 |
| Description | AC Gearmotor |
| Technical specification | Parallel, Single Output Shaft, PSC, TENV, 124 RPM, 25 in-lb Max Torque, 115V AC Nameplate Speed 124 RPM Maximum Torque 25 in-lb Input Horsepower 0.05 hp Overhung Load Capacity 90 ft-lb Phase Single Operating Voltage 115V AC Full Load Current 0.6 A Rotation CW/CCW Base to Center of Shaft 1.19 in Shaft Orientation Parallel Number of Output Shafts 1 Motor Type Permanent Split Capacitor Motor Enclosure Totally Enclosed Nonventilated Mounting Orientation Any Angle Inverter Rated No Thermal Protection None Maximum Ambient Temperature 104 °F Capacitor Required Yes Compatible Capacitor 2MDV6 Gear Ratio 13:1 Gear Type Helical (1st Stage); Spur (Subsequent Stages) Gear Material Steel or Heat Treated Powdered Metal Brake Type None Output Shaft Diameter 1/2 in Output Shaft Length 1 in Keyway Type Rounded Keyway Width 1/8 mm Keyway Depth 0 in Bearing Type Ball on Motor; Heavy Duty Needle on Case Seal Type Spring Loaded Lip Type on Input and Output Shaft Lubrication Permanent Heavy Duty Gear Oil Housing Material Die Cast Aluminum Mount Type Any Position Mount Hole Center-to-Center Width 2.38 in Length Less Shaft 7.38 in Overall Width 5.25 in Overall Height 3.94 in Application Ball on Motor; Heavy Duty Needle on Case Standards C-UL Recognized; UL Recognized Frequency 60 Hz UNSPSC 26101602 |
| Weight | 2.5 |
Please contact us to request a price quote for DAYTON - 6Z084, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 6Z084 by DAYTON in United Kingdom?
You can purchase 6Z084 by DAYTON from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 6Z084?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of DAYTON in United Kingdom?
While we are not the official distributor or seller of DAYTON in United Kingdom, we source our products from reliable channels and offer you original DAYTON equipment at competitive prices.
How can I access 6Z084 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 6Z084 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 6Z084?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
