Demag - EUDC-Pro 5-500 1/1 H32 V8/2 380-415/50 24/6 200 220-480

Manufacturer Demag
Part Number EUDC-Pro 5-500 1/1 H32 V8/2 380-415/50 24/6 200 220-480
Inner Code 5120033
Description DEMAG Electric Chain Hoist
Technical specification

The Demag DC-Pro chain hoist meets all the requirements of a quality Demag product and sets standards for
Industry standard for hoists. It is a highly flexible chain hoist that can be installed within a very short period of time and
can be put into operation. The DC-Pro is characterized by high ease of use, high productivity, optimal
Use of room height and maximum reliability from and will both economic and
meets the safety-relevant requirements of a modern hoist. The standard package includes the following
Equipment included: - Contactor control with 24V control voltage (with internal tri-state signal transmission) - One
Operating limit switch for the highest and lowest hook position, to safely switch off the chain hoist in the end positions -
An operating hours meter that can be read from the outside - Two standard stroke speeds as main and fine stroke - The
Speed-controlled brake and clutch principle ensures a high level of safety and a long service life - transmission, brake
and couplings are maintenance-free for up to 10 years - For service purposes, the operating parameters can be controlled via an optical
display or be read out wirelessly from the chain hoist control via the built-in infrared diagnostic interface -
A central service room that provides quick and direct access to all important connectors and a simple
Chain lubrication enabled - All electrical connections directly on the chain hoist are pluggable. - Faster and easier
Changing the chain drive without disassembling the motor or transmission part


supply network
Line voltage 400 V
Line frequency 50 Hz
3-phase three-phase network type
Technical data chain hoist
Load capacity 500 kg
FEM/ISO group 2m+/M5+ (20% more than 2m/M5)
Hakenweg 32 m
Control cable length 28.8 m
Weight approx. 78 kg (net total)
Consolidation 1/1
Lifting speed approx. 8/2 m/min

Control voltage 24V AC
Hoist voltage 380-415 V/ 50 Hz
ZNK 80 B 8/2 lift motor
Operating time 40/20%
Rated power 0.73/0.18 kW
Protection class IP 55
Insulation class F
Ambient temperature -20 °C to +45 °C
C dimension 416 mm
Surface protection and coloring
Hoist and chassis colour RAL 5009 azure blue
High-quality powder coating of the aluminum components of the chain hoist ensures excellent corrosion protection.
Chain storage flexible chain storage for support roller U11 designed for 32 m hook travel chassis - The chassis is
Continuously adjustable to the appropriate flange width - standard chassis with fall protection and lateral
Guide rollers to protect running gear and chassis rollers - Integrated climbing protection - Universal rollers for
Profile carrier Chassis technical data
Model EU11-200
flange width 58 - 200 mm
Flange thickness max 22 mm
Flange height min 91 mm
Traction drive - electronic control with wide voltage input - control voltage 24 V, internal
Tri-state signal transmission to the DC chain hoist. - All electrical connections are pluggable. inputs for
Limit switches and pre-limit switches are integrated on the control card. Soft start via ramps. - Overheating protection by
Temperature monitoring. - The drive is attached to the respective underflange chassis. - The drive is
Delivered ready for use. - In addition, the following settings can be made: The travel speed, the
If required, acceleration and deceleration ramps can be used for specific applications via the control switch
Can be parameterized. - 2 rollers driven Technical data Cat drive
Travel speeds 24/6 m/min
E11-2WD drive
Operating time 35/15%
Rated drive power 0.1/0.025 kW
Rated current 1.1/0.3 A
Engine speed 3450/862 min¹
The electrically movable chain hoist is delivered in assemblies. These must be assembled on site. assemblies
consisting of: - DC chain hoist - chassis/drive motor control unit control cable with control switch
Control switch: DSE-10C
Control cable: 2TY 28.8 m control cable
Weight 78
