Dwyer - DH-008
| Manufacturer | Dwyer |
|---|---|
| Part Number | DH-008 |
| Inner Code | 5047262 |
| Description | Digihelic Differential Pressure Controller |
| Technical specification | Service Air and non-combustible, non-conducting compatible gases Wetted Materials Consult factory Housing Material ABS plastic, UL approved 94-V-0 Accuracy ±0.5% at 77°F (25°C) including hysteresis and repeatability Stability ≤±1% per year Temperature Limits 32 to 140°F (0 to 60°C) Compensated Temperature Limits 32 to 140°F (0 to 60°C) Thermal Effects 0.020%/°F (0.036/°C) from 77°F (25°C) Low Voltage Power 24 VAC ±20% High Voltage Power 100 to 240 VAC, 132 to 240 VDC - 7 VA max Output Signal 4 to 20 mA DC into 900 ohms max Response Time 250 ms Display 4 digit LCD 0.4" height. LED indicators for set point and alarm status Electrical Connections Screw terminals Process Connections Compression fitting for use with 3⁄16" OD x ⅛" ID tubing Enclosure Rating Face designed to meet NEMA 4X (IP66) Mounting Orientation Mount unit in horizontal plane |
| Weight | 0.408 |
Please contact us to request a price quote for Dwyer - DH-008, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DH-008 by Dwyer in United Kingdom?
You can purchase DH-008 by Dwyer from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the DH-008?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Dwyer in United Kingdom?
While we are not the official distributor or seller of Dwyer in United Kingdom, we source our products from reliable channels and offer you original Dwyer equipment at competitive prices.
How can I access DH-008 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DH-008 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DH-008?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
