EBM Papst - W3G910LV1015

Manufacturer EBM Papst
Part Number W3G910LV1015
Inner Code 5144655
Description EC axial panel fan - AxiBlade
Technical specification

Weight 55.5 kg
Size 910 mm
Motor size 150
Rotor surface Painted black
Electronics housing material Die-cast aluminum, painted gray
Impeller material PP plastic
Fan housing material Sheet steel, galvanized and coated with black plastic (RAL 9005)
Material guide vanes PP plastic
Guard grille material Steel, coated with black plastic (RAL 9005)
Internal diffuser material
including cover
PP plastic
Number of blades 5
Blade pitch 0°
Airflow direction V
Direction of rotation Clockwise, viewed toward rotor
Degree of protection IP55
Insulation class "F"
Moisture (F) / Environmental (H)
protection class
H2
Ambient temperature note Occasional start-up at temperatures between -40°C and -25°C is permitted. For
continuous operation at ambient temperatures below -25°C (such as refrigeration
applications), use must be made of a fan design with special low-temperature bearings.
Max. permitted ambient temp.
for motor (transport/storage)
+80 °C
Min. permitted ambient temp. for
motor (transport/storage)
-40 °C
Installation position Shaft horizontal or rotor on bottom; rotor on top on request
Condensation drainage holes On rotor side
Mode S1
Motor bearing Ball bearing
Technical features - Operation and alarm display with LED
- External 15-50 VDC input (parameterization)
- Alarm relay
- Integrated PI controller
- Configurable inputs/outputs (I/O)
- MODBUS V6.3
- Motor current limitation
- RS-485 MODBUS-RTU
- Soft start
- Voltage output 3.3-24 VDC, Pmax = 800 mW
- Control interface with SELV potential safely disconnected from the mains
- Thermal overload protection for electronics/motor
- Line undervoltage / phase failure detection
EMC immunity to interference According to EN 61000-6-2 (industrial environment)
EMC interference emission According to EN 61000-6-3 (household environment)
Touch current according to IEC
60990 (measuring circuit Fig. 4,
TN system)
<= 3.5 mA
Electrical hookup Terminal box
Weight 55.5
