Electro Adda - FC132S-4B5
| Manufacturer | Electro Adda |
|---|---|
| Part Number | FC132S-4B5 |
| Inner Code | 276316 |
| Description | electric motor |
| Technical specification | electric motor Typ FC132S-4B5 5,5 KWT; 1440 U/min Main specifications Brand Electro Adda Item Number FC132S-4-B5 Electro Adda Category 3-Phase Motors Weight and Dimensions Weight (kg) 50 Product Properties Rated power (kW) 5.5 Speed at 50Hz (rpm) 1500 / 4-Poles Frequency 50 Hz Energy efficiency IE2 = High = EFF1 Mounting B5 (outer flange) Brake No Brake IP Class IP55 Explosion safety (Atex) No protection IEC Framesize 132 Detailed Product Properties Voltage 380-400VD / 660-690VY IEC Framesize 132 Shaft diameter (mm) 38 Housing material Alu AC/DC AC Standard IEC Shaft height IEC in JDE 132 Shaft length (mm) 80 Shaft key width (mm) 10 Shaft key length (mm) 70 Thread shaft bore M12 Shaft height, B3 mounted (mm) 132 Width foot holes, B3 mounted (mm) 216 Length foot holes, B3 mounted (mm) S=286, M=311 Diameter foot holes (mm) 12 Outer diameter flange B5/V1/B35/V3 (mm) 300 Spigot B5/V1/B35/V3 (mm) 230 Pitch circle diameter B5/V1/B35/V3 (mm) 265 Number of flange holes 4 Diameter flange holes B5/V1/B35/V3 (mm) 14.5 Pitch circle diameter B14/B34/V18/V19 (mm) 165 Thread flange holes B14/B34/V18/V19 M10 Outer diameter flange B14/B34/V18/V19 (mm) 200 Spigot B14/B34/V18/V19 (mm) 130 |
| Weight | 1 |
Please contact us to request a price quote for Electro Adda - FC132S-4B5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy FC132S-4B5 by Electro Adda in United Kingdom?
You can purchase FC132S-4B5 by Electro Adda from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the FC132S-4B5?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Electro Adda in United Kingdom?
While we are not the official distributor or seller of Electro Adda in United Kingdom, we source our products from reliable channels and offer you original Electro Adda equipment at competitive prices.
How can I access FC132S-4B5 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for FC132S-4B5 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for FC132S-4B5?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
