Elgo - 733280189, type LMIX2-000-04.0-1-01

Manufacturer Elgo
Part Number 733280189, type LMIX2-000-04.0-1-01
Inner Code 1832550
Description Incremental Linear Encoder with Integrated Interpolation
Technical specification
  • Model: LMIX2-000-04.0-1-01
  • Manufacturer: Elgo
  • Measuring Principle: Incremental Magnetic Measurement
  • Resolution: 0.025 mm (at 4-edge triggering)
  • Repeat Accuracy: ±1 increment
  • System Accuracy: ±(25 + 20 x L) µm at 20°C, where L is the measuring length in meters
  • Distance Sensor/Tape: Max. 2.0 mm
  • Sensor Housing Material: Zinc Die-Cast
  • Housing Dimensions: 30 x 12.5 x 25 mm
  • Pole Pitch: 5 mm
  • Maximum Measuring Length: Theoretically unlimited
  • Connections: Open cable ends
  • Sensor Cable: 4.0 meters
  • Power Supply Voltage: 10 ... 30 VDC
  • Output Signals: A, A', B, B', Z, Z'
  • Output Levels: TTL
  • Output Current per Channel: Max. 20 mA
  • Maximum Output Frequency per Channel: 100 kHz
  • Operating Speed: Up to 5 m/s
  • Operating Temperature: -10°C to +70°C
  • Protection Class: IP67
Weight 1
