Ephy Mess - 986180110000003 - PR-SPA-EX-LTH
| Manufacturer | Ephy Mess |
|---|---|
| Part Number | 986180110000003 - PR-SPA-EX-LTH |
| Inner Code | 4901333 |
| Description | Screw-in resistance thermometer |
| Custom Code | 90259000 |
| Technical specification | iBExu 14 ATEX 1291 X, II 2G Ex ia IIC T6... T3 Gb please_note_manual_point_10 Screw-in resistance thermometer, LT-38, 2Pt100, 3-wire circuit Class A ±0.15°C at 0°C in accordance with DIN EN 60751 EM38 connection head, nickel-plated brass Size: ø6x480mm, cover: no, Sealed: yes Cable outlet: M20x1.5 - pressure screw VSB: mobile, stainless steel, NPT 1/2"/SW 27 Cutting ring: stainless steel, ø6.1mm Supply line: 1x shielded hose cable [8x0.5mm²-Cu-tin-plated/silicone 2g/polyester film/Cu-tin-plated/PE- foil/stainless steel/silicone 2G, Kl=5000mm, diameter: 8.5mm] BU (RD/RD/WH/BK/BK/YE), Measurement range: -60°C... +180°C Ambient temperature: -60°C... +100°C Dielectric strength: 2.0 kV AC. 50 Hz/1min. Dielectric strength: element to element: 0.5 kV AC. 50 Hz/1min. Shield not placed on the sensor housing Orders from 12.11.2019 have a lower measurement and Ambient temperature range of -60°C. Through the previously used components Only -50°C were possible. |
| Weight | 0.945 |
Please contact us to request a price quote for Ephy Mess - 986180110000003 - PR-SPA-EX-LTH, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
