Erhardt Leimer - 0010 331906

Manufacturer Erhardt Leimer
Part Number 0010 331906
Inner Code 4005431
Description Complete centering device
Technical specification ELGUIDER - DRS 2292 rotating frame system with swivel frame DR 2275 in compact design, to control a running web, with digital position controller and electrical actuator. - Attachment to two customer-side rods - Transparent control panel cover - fine adjustment of the sensor - Stainless steel sensor rod with scale - Sensor address 02 Country of origin: DE HS 90328900 With the following configuration: E + L system: DRS2292 DR - series: DR 2275 Nominal width NB: 250 mm Transfer length LUE: 250 mm Guiding system: web edge control Sensor: FX 45 ultrasonic sensor Operating voltage: 24V DC 2.5A Roller diameter: 60 mm Roller surface infeed: AL- bright Roller surface outlet: Al rubber cork Control unit: RT 4006 standard Data format: standard Installation arrangement: 11-E1-A1-B-LR Works standard: 555720 Assembly: with slot nuts Correction path max .: 29 mm Color: RAL 7021 dark gray Special version: KBS7145 from Krones
Weight 15

Please contact us to request a price quote for Erhardt Leimer - 0010 331906, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy 0010 331906 by Erhardt Leimer in United Kingdom?

You can purchase 0010 331906 by Erhardt Leimer from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the 0010 331906?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Erhardt Leimer in United Kingdom?

While we are not the official distributor or seller of Erhardt Leimer in United Kingdom, we source our products from reliable channels and offer you original Erhardt Leimer equipment at competitive prices.

How can I access 0010 331906 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 0010 331906 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 0010 331906?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Erhardt Leimer-0010 331906 price
4 / 5
★ ★ ★ ★ ★
(9)
Comments

More products of Erhardt Leimer

  • 00320961

    controller

  • 00320961

    DC 1340 digital position controller in housing, RT with control panel 4019, according to dimension sheet 157873, Data Protocol 1.0, Output voltage 22 V, output current 7 A, for digital sensors, operating voltage 24 V DC

  • 00323229

    2m Telescopic electric line

  • 00323230

    electric eye cable

  • 00329557 FR 1501 KANTENSENSOR LINKS

    FR 1501 left edge sensor

  • 00329558 FR 1501

    INFRARED EDGE SENSOR

  • 00331069

    SW_9500-9501 actuator digital +/- 75 M = 433 1000 N Origin: European Union (DE) HS84439199

  • 00331069

    SW_9500-9501 actuator digital +/- 75 M = 433 1000 N

  • 00333787 FE 5002 mit Zylinderlinse

    Farbliniensensor digital

  • 00333787 FE 5002

    Color line sensor digital,with cylindrical lens, per measurement 157272,Measuring range +/- 10 mm, membrane keyboard withLED display scale, pluggable,Operating voltage 24 V DC, IP 65Data Log 1.0Origin: European Union (DE)HS 85414090

  • 00343543

    DC 5501 Digitaler Regler mit Gehäuse

  • 00343543

    (DC 5501 Digital Controller with housing with CAN controller card, Power stage PK 5511 and fans, and interfaces for Peripherals and software for KRS, Display Language: English / Chinese, Dimensions 283 x 232 mm x 111 Operating voltage 34 V AC 500 W Origin: European Union (DE) HS 90328900)

  • 00347003 KR 5230

    (Actuator per measurement 157987, DC gear motor, Incremental encoder output pinion, Rack lock Flanschsäule 362 mm long with clamping ring and mounting the sleeve for Actuator, IP 54 Force 1230 N Adjusting speed 120 mm / s Origin: European Union (DE) HS 84798997)

  • 00349658

    approach switch (including 5m cable)

  • 00352105

    FX 4631 edge sensor ultrasound, digital, Range +/- 3mm, internal width 30 mm, with 300 mm cable and straight connector M16

  • 00363591

    FX 5230 edge sensor ultrasound, digital, Range +/- 10 mm, per measurement 158320 with microprocessor, software Dat.Prot. 1.0 + 2.0 LED display scale with keyboard, M16 connector for operating voltage 24 V DC and CAN bus, IP 54, inside diameter 30 mm, depth 52 mm Fork

  • 00364129

    FR 5503 infrared edge sensor Clamping frame according to drwg 158289, Range +/- 10 mm with microprocessor, LED indicator scale with keyboard, Plug for operating voltage 24 V and CAN bus, with mechanical scanning. Origin: European Union (DE) HS 90314990

  • 00394138

    infrared edge sensor

  • 00227831

    KF 2020 web leader left

  • KF 2020 (00227833)

    Warenbahnführer right

  • AG2595 NR226921

    driving motor

  • 00302990 / CV 2201

    Web voltage measuring amplifier

  • 00343543 DC 5501

    Digital controller

  • DO2000

    Operator Panel

  • EBM 6133-0350 PART NO: 337154

    LOAD CELL, STOCK CODE Y.007905
