Faulhaber - 1028.00100 / 1028S012B
| Manufacturer | Faulhaber |
|---|---|
| Part Number | 1028.00100 / 1028S012B |
| Inner Code | 4724951 |
| Description | Brushless DC-Servomotor |
| Technical specification | Values at 22° and nominal voltage Value Nominal voltage UN 12 V Terminal resistance, phase-phase R 4.37 Ω Efficiency, max. ηmax. 72 % No-load speed n0 33600 min⁻¹ No-load current I0 0.065 A Stall torque MH 9.22 mNm Friction torque, static C0 0.06 mNm Friction torque, dynamic CV 4.62 ·10⁻⁶ mNm/min⁻¹ Speed constant kn 2825 min⁻¹/V Back-EMF constant kE 0.354 mV/min⁻¹ Torque constant kM 3.38 mNm/A Current constant kI 0.296 A/mNm Slope of n-M curve Δn/ΔM 3653 min⁻¹/mNm Terminal inductance, phase-phase L 87 µH Mechanical time constant τm 2.1 ms Rotor inertia J 0.0622 gcm² Angular acceleration αmax. 1711 ·10³rad/s² Thermal resistance Rth1/Rth2 6.6 / 42.4 K/W Thermal time constant τw1/τw2 4.2 / 152 s Operating temperature range -20 ... 100 °C Winding temperature, max. 125 °C Housing material aluminium, black anodized Direction of rotation electronically reversible Speed up to nmax. 79000 min⁻¹ Number of pole pairs 1 Hall sensors digital Magnet material NdFeB |
| Weight | 0.009 |
Please contact us to request a price quote for Faulhaber - 1028.00100 / 1028S012B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 1028.00100 / 1028S012B by Faulhaber in United Kingdom?
You can purchase 1028.00100 / 1028S012B by Faulhaber from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 1028.00100 / 1028S012B?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Faulhaber in United Kingdom?
While we are not the official distributor or seller of Faulhaber in United Kingdom, we source our products from reliable channels and offer you original Faulhaber equipment at competitive prices.
How can I access 1028.00100 / 1028S012B catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1028.00100 / 1028S012B on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1028.00100 / 1028S012B?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
