Fristam - FPR752-240 - FPR7521806249
| Manufacturer | Fristam |
|---|---|
| Part Number | FPR752-240 - FPR7521806249 |
| Inner Code | 4802633 |
| Custom Code | 84137051 |
| Technical specification | 0460000003 centrifugal pump FPR 752/240 Pump material: New (see below) Shaft seal: 858 (simple) see below Elastomers: see below Suction Side Connection Type: Sanitary Clamp Pressure side connection type: Sanitary clamp Suction side connection size: DN 3 ́ ́ Pressure side connection size: DN 2 ́ ́ pump Casing Drain Type: 1/2", Straight, Sanitary Clamp Piping option: option D Pump Orientation: 45° Left Flange Option: Cast Iron Flange Support Paint Color: No Paint on Motor/Fristam Gray Painted Flange paint No painting Impeller/Displacer - Impeller diameter: 240 GLRD Housing Seal Size: 758 Rotating Seal: Silicon Carbide Stationary Seal: Silicon Carbide Seal Elastomers: Class VI Viton Newman Compound #3207 Cover Gasket: Class VI Viton Newman Compound #3207 Material Pump material: 316L stainless steel motor - Power: 25 HP/- kW - Voltage: 230/ 460 V - Speed: 3500 rpm - Frequency: 60 Hz Hz - Protection class: IP 55 Engine manufacturer: Toshiba Frame size: 284TSC Engine enclosure: TEFC - Toshiba Severe Duty (IP55) Engine Efficiency: Premium Efficiency Engine Service Factor: 1.15 Funding data - Material to be transported: - other agreements Elastomer Cert: Elastomer Certification Mill Certification: Chemical Analysis with Heat Numbers Certified Finish: Map Of Surface (Ra For Wetted Parts) Cert of Conformance: Statement Included Ship Docs. w/ Pump: Ship Documents With Pump |
| Weight | 25 |
