FSG Fernsteuergeräte - 1896Z10-009.002
| Manufacturer | FSG Fernsteuergeräte |
|---|---|
| Part Number | 1896Z10-009.002 |
| Inner Code | 4480535 |
| Description | Cable travel switch with voltage output |
| Custom Code | 90318020 |
| Technical specification | G015-PK620D-R/U-2SEN/E0/GS120 in aluminum housing protection class IP 65 electr. Connection via plug-in device with mating connector Housing 120 mm Ý installation depth 130 mm Double ball bearing drive shaft 12h7 Ý free wavelength 30mm shaft with feather key according to DIN with 3 flange-side thread holes M6 12mm deep N/Zg. 1896 Z 10 with low-backlash adjustment gear 20:1 slow with plastic potentiometer PK620d/MU-U01 1574Z05-001.003 with integrated R/U converter for output 0-10V at RA min 500Û with counterclockwise rotation of the drive shaft 20-30VDC power 4-wire circuit with galv. separation between supply and output with a built-in forced separate cam limit switch switching point position by means of screw adjustable turner with motorized grinder and Switch reset within from 30 to 40 sec (direction 0 V) |
| Weight | 2.1 |
