Georgin - DFML10HX

Manufacturer Georgin
Part Number DFML10HX
Inner Code 4038643
Description DFML10HX Differential pressure switch 0 - 80 mbar
Custom Code 90322000
Technical specification 410085 DFML10HX Differential pressure switch 0 - 80 mbar F Series Differential Pressure Switches Degree of protection: IP66 Housing: Mazak, epoxy coated, Stainless steel screws Measuring range: 0 - 80 mbar Max. static pressure: +/- 300 mbar Sensor element: Diaphragm BunAn Material: BunaN - 304L stainless steel flange Process connection: 1/2" GM 1 relay SPDT dry contact tight deadband Fixed deadband: <1.4mbar Amperage: 5A/240V - 0.5A/130V Cable Gland: Polyamide M16 (D: 5-10) Item code: 0FD10BEMY0000 Customs tariff No: 9032 2000 Origin: France, EU
Weight 2.6

Please contact us to request a price quote for Georgin - DFML10HX, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy DFML10HX by Georgin in United Kingdom?

You can purchase DFML10HX by Georgin from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the DFML10HX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Georgin in United Kingdom?

While we are not the official distributor or seller of Georgin in United Kingdom, we source our products from reliable channels and offer you original Georgin equipment at competitive prices.

How can I access DFML10HX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DFML10HX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DFML10HX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Georgin-DFML10HX price
4 / 5
★ ★ ★ ★ ★
(8)
Comments

More products of Georgin

  • 0FP06BVLX0300 REF. FPL6VX

    Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 25 to 400 bar max. pressure : 600 bar sensing element : Bourdon tube material : 316Ti st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <32 to 200 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

  • 0FP54BQSX0300 REF. FP54QX

    (Pressure switch F series protection: IP66 housing: mazak, epoxy painted range: 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material: 316L st. st. process connection : 1/2"NPTM switch: 2 separate tropicalized SPDT adj. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) )

  • 0PD06BCB00200 REF. DMPB6M11

    Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)

  • 17A2E4

    Intrinsically Safe Control

  • BVNS0B00-00-00

    Insulator 230V AC, input/output 4-20mA

  • bzg788+

    Zener Barriere

  • BZG796

    Zener diode

  • FC 54T

    range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper

  • FC6GXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FC6PXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FP4DRX

    Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.

  • FP4K, Art. N: 0FP04BKS00000

    Pressure switch F series

  • FP54QX

    Pressure switch

  • FP62P

    Pressure switch F series

  • GR5000S00 (0/50 BAR)

    (Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)

  • GR7000S00

    Drucktransmitter

  • GRE000S00

    Drucktransmitter

  • GRK000S00

    Drucktransmitter

  • OFP06BPSYO3A0 (FP6PX)

    SWITCH PRESSURE

  • P16AX40A6

    (Pressure switch)

  • PA36K

    pressure Switch

  • PHB34SX

    (Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)

  • SEALING DEVICE - F SERIES

    material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000

  • FP6K+S680

    Druckschalter mit Flansch
