Georgin - FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU

Manufacturer Georgin
Part Number FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU
Inner Code 562837
Description Differential pressure transmitter
Custom Code 90262020
Technical specification Ref. FKC (10 / 600 mmCE) type FKC min/max span limits : 10 / 600 mmCE static pressure: -1/100 bar Calibrated span : *** to confirm *** Accurancy if span > 1/10 URL : +/-0.065% calibrated span Process connection : 1/4"-18 NPT measuring diaphragm: 316L St. St. Fill fluid : silicon oil flange: 316 st. st. Viton process cover gasket oval flange connection: 7/16-20 UNF bolds & screws: 316 stainless steel (M10) other wetted parts: 316 st. st. treatment: standard Power Supply : 10.5 to 45 Vdc electrical connection: 1/2" - 14 NPT Output signal : 4..20mA (two-wires tech.) + HART RFI protection (acc. to IEC 801-3) Housing : die-cast alu. alloy - Polyester coating Approval: Intrinsic Safety (ATEX) Equipped with a digital display (custom scale) Refer necessarily to corresponding datasheet Supplied with st.st. Bracket for 2inchs mounting
Weight 3.2

Please contact us to request a price quote for Georgin - FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU by Georgin in United Kingdom?

You can purchase FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU by Georgin from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Georgin in United Kingdom?

While we are not the official distributor or seller of Georgin in United Kingdom, we source our products from reliable channels and offer you original Georgin equipment at competitive prices.

How can I access FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Georgin-FKCT22V52KCBYAU old code; new code FKCT22V5PCBYAU price
5 / 5
★ ★ ★ ★ ★
(1)
Comments

More products of Georgin

  • 0PD06BCB00200 REF. DMPB6M11

    Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)

  • 17A2E4

    Intrinsically Safe Control

  • BVNS0B00-00-00

    Insulator 230V AC, input/output 4-20mA

  • bzg788+

    Zener Barriere

  • BZG796

    Zener diode

  • FC 54T

    range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper

  • FC6GXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FC6PXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FP4DRX

    Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.

  • FP4K, Art. N: 0FP04BKS00000

    Pressure switch F series

  • FP54QX

    Pressure switch

  • FP62P

    Pressure switch F series

  • GR5000S00 (0/50 BAR)

    (Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)

  • GR7000S00

    Drucktransmitter

  • GRE000S00

    Drucktransmitter

  • GRK000S00

    Drucktransmitter

  • OFP06BPSYO3A0 (FP6PX)

    SWITCH PRESSURE

  • P16AX40A6

    (Pressure switch)

  • PA36K

    pressure Switch

  • PHB34SX

    (Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)

  • SEALING DEVICE - F SERIES

    material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000

  • FP6K+S680

    Druckschalter mit Flansch

  • WGX232

    Pressure indicator
