Georgin - FKCT35V52ACBYAU

Manufacturer Georgin
Part Number FKCT35V52ACBYAU
Inner Code 562836
Description Differential pressure transmitter
Custom Code 90262020
Technical specification Ref. FKC (0.13 / 13 mCE) type FKC min/max span limits : 0.13 / 13mmCE static pressure: -1/160 bar Calibrated span : *** to confirm *** Accurancy if span > 1/10 URL : +/-0.065% calibrated span Process connection : 1/4"-18 NPT measuring diaphragm: 316L St. St. Fill fluid : silicon oil flange: 316 st. st. Viton process cover gasket oval flange connection: 7/16-20 UNF bolds & screws: 316 stainless steel (M10) other wetted parts: 316 st. st. treatment: standard Power Supply : 10.5 to 45 Vdc electrical connection: 1/2" - 14 NPT Output signal : 4..20mA (two-wires tech.) + HART RFI protection (acc. to IEC 801-3) Housing : die-cast alu. alloy - Polyester coating Approval: standard Equipped with a digital display (custom scale) Refer necessarily to corresponding datasheet Supplied with st.st. Bracket for 2inchs mounting
Weight 3.2

Please contact us to request a price quote for Georgin - FKCT35V52ACBYAU, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy FKCT35V52ACBYAU by Georgin in United Kingdom?

You can purchase FKCT35V52ACBYAU by Georgin from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the FKCT35V52ACBYAU?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Georgin in United Kingdom?

While we are not the official distributor or seller of Georgin in United Kingdom, we source our products from reliable channels and offer you original Georgin equipment at competitive prices.

How can I access FKCT35V52ACBYAU catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for FKCT35V52ACBYAU on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for FKCT35V52ACBYAU?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
