Gmn - 1063603
| Manufacturer | Gmn |
|---|---|
| Part Number | 1063603 |
| Inner Code | 4875828 |
| Description | lubricator |
| Custom Code | 8479 8960000 |
| Technical specification | - with built-in oil-air mixing distributor - Number of lubrication outlets: 2 (plug connections) - Lubrication line outer diameter: 6 mm - Lubrication line length between oil-air lubricator and spindle: max. 5 m - Oil dosing rate per pulse and per outlet: 30 mm³ - Compressed air connection: G 1/4, recommended screw connection for inner hose diameter 9 mm Attention: Screwing is not included! - Pressure air pressure network: min. 6 bar (min. 4 bar under certain conditions, see operating instructions) - built-in compressed air and fine oil filter - 2.7 liter oil container, 1.2 liter removal capacity - 2-stage level switch (warning and alarm) - Plug connection for electrical connection, included mating plug in the device - Supply voltage: 90-260 VAC, 50/60 Hz - max. backup: 6 A - Power consumption: 200 W - Device control with function control and fault message - Dimensions with attachments approx. 484 mm x 432 mm x 222 mm (W x H x D) - Weight: approx. 19 kg - Housing color: RAL 7032 (pebble gray) |
| Weight | 18.82 |
Please contact us to request a price quote for Gmn - 1063603, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 1063603 by Gmn in United Kingdom?
You can purchase 1063603 by Gmn from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 1063603?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Gmn in United Kingdom?
While we are not the official distributor or seller of Gmn in United Kingdom, we source our products from reliable channels and offer you original Gmn equipment at competitive prices.
How can I access 1063603 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1063603 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1063603?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
