Gmn - GP-S 90-260 V
| Manufacturer | Gmn |
|---|---|
| Part Number | GP-S 90-260 V |
| Inner Code | 4756132 |
| Description | Lubricator |
| Custom Code | 8479 8960000 |
| Technical specification | RAL 7032 - without oil-air mixing distributor - Compressed air connections: input G 1/2, recommended screw connection for inner hose diameter 9... 13 mm depending on the air requirement of the spindles to be supplied G 1/2 outlet, recommended screw connection for inner hose diameter 9... 13 mm depending on the air requirement of the spindles to be supplied Attention: Compressed air fittings are not included! - Air pressure network: min. 6 bar (min. 4 bar under certain conditions, see operating instructions) - Total air flow: approx. 38 Nm³/h at 5 bar working air pressure - Number of lubrication ports: max. 12 when operating spindles with a sleeve diameter of up to 150 mm max. 8 when operating spindles with a sleeve diameter greater than 150 mm - Pressure oil connection (outlet): hydraulic screw connection for external pipe diameter 6 mm - built-in compressed air and fine oil filter - oil container 2.7 liters, removal quantity 1.2 liters - 2-stage level switch (warning and alarm) - Plug connection for electrical connection, matching plug included in the device - Supply voltage: 90-260 VAC, 50/60 Hz - max. back-up protection: 6 A - Power consumption: 200 W - Device control with function control and fault message - Dimensions with attachments and plug connector approx. 528 mm x 432 mm x 222 mm (W x H x D) - Housing color: RAL 7032 (pebble gray) |
| Weight | 18.39 |
Please contact us to request a price quote for Gmn - GP-S 90-260 V, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
