Gutekunst - D-063H
| Manufacturer | Gutekunst |
|---|---|
| Part Number | D-063H |
| Inner Code | 4015542 |
| Description | Compression Spring |
| Custom Code | 73202089 |
| Technical specification | Mat EN 10270-1 - type of material s2 mm Loaded spring deflection L2 mm Loaded spring length F2 N Loaded spring force Fdn Closed - spring ends d 0.4 mm Wire diameter D 1.8 mm Mean coil diameter Dd 1.1 mm maximum diameter of mandrel De 2.2 mm Outer coil diameter Detol 0.1 mm (+/-) tolerances of outer coil diameter Dh 2.5 mm minimum diameter of bush F1tol N (+/-) tolerance of prestressed spring force F2tol N (+/-) tolerance of loaded spring force Fn 17.816 N maximum force in static use Fntol 1.52 N (+/-) tolerance of maximum force in static use Lk 9.77 mm buckling length L0 13 mm unstressed spring length L0tol 0.34 mm (+/-) tolerance of unstressed spring length L1 mm Prestressed spring length Ln 8.02 mm Minimum length in static use s1 mm Prestressed spring deflection sn 4.98 mm Maximum spring deflection in static use S 0.96 mm pitch of spring n 12.5 pc. number of active coils nt pc. total number of coils R 3.578 N/mm Spring rate Fndyn 14.668 N maximum force in dynamic use Fndtol 1.45 N (+/-) tolerance of maximum dynamic force Lndyn 8.9 mm Minimum length in dynamic use shdyn 0.52 mm Maximum stroke in dynamic use |
| Weight | 0.0814 |
Please contact us to request a price quote for Gutekunst - D-063H, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy D-063H by Gutekunst in United Kingdom?
You can purchase D-063H by Gutekunst from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the D-063H?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Gutekunst in United Kingdom?
While we are not the official distributor or seller of Gutekunst in United Kingdom, we source our products from reliable channels and offer you original Gutekunst equipment at competitive prices.
How can I access D-063H catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for D-063H on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for D-063H?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
