HanYoung NUX - HY-LS803N
| Manufacturer | HanYoung NUX |
|---|---|
| Part Number | HY-LS803N |
| Inner Code | 3766308 |
| Description | N type mini limit switches |
| Technical specification | N type mini limit switches; Article No. : 80400803 Model / Type : HY-LS803N. Contact structure : M3 screw tightening terminal, 2 circuits double type (1a1b). Contact material : AgNi. Protective structure : P54 (Only when using our company product HYC-M1, M2 in the wire opening). Rated current : 6 A. 250 V a.c, 4 A. 30 V d.c (AC-12, AC-13, AC-15, DC-13). Dielectric strength : 2,000 V a.c 50/60 ㎐ for 1 min (between the terminal and non-recharing metal part). Insulation resistance : Min. 100 MΩ (500 V d.c insulated ohmmeter). Contact resistance : Max 25 MΩ default value). Rated voltage (Ue) : 250 V a.c, 30 V d.c. Actuator intensity : 5 Times larger than O.F (required force for the operation), operating direction 1 min. Vibration : Double amplitude 1.5mm, frequency 10 ~ 55 ㎐, continuously 2 hour. Shock : 100 m/s² (durability), 50 m/s² (malfunction). Allow. Oper. Speed : 0.1 ~ 0.5 m/s (without damaging the actuator). Mechanical life : Min. 1 million times (less than open/close frequency 120 times/min). Electrical life : Min. 100 thousand times (less than open/close frequency 30 times/min). Ambient Temp. : -10 ~ 70 ℃. Ambient Humidity : 45 ~ 95 % R.H. Weight : Approx 60g (HY-LS803N). |
| Weight | 0.06 |
Please contact us to request a price quote for HanYoung NUX - HY-LS803N, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy HY-LS803N by HanYoung NUX in United Kingdom?
You can purchase HY-LS803N by HanYoung NUX from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the HY-LS803N?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HanYoung NUX in United Kingdom?
While we are not the official distributor or seller of HanYoung NUX in United Kingdom, we source our products from reliable channels and offer you original HanYoung NUX equipment at competitive prices.
How can I access HY-LS803N catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for HY-LS803N on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for HY-LS803N?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
