D60-A80ICL4 HIMMEL Sales In United Kingdom
| Manufacturer | HIMMEL |
|---|---|
| Part Number | D60-A80ICL4 |
| Inner Code | 4317687 |
| Description | helical geared motor |
| Custom Code | 85015100 |
| Technical specification | 2230070762 Dimension sheet: DZ01 Transmission type/ type: HIMMEL® helical geared motor/HIMMEL® -helical gear engine Transmission type/ type: D60-A80ICL4 Dimension picture/dimension sheet: DZ01 Output speed/ output speed [rpm; 1/rpm]: 10.00 translation/ratio [i]: 144.41 Color/colour: RAL 5015 sky blue 2K/sky blue 2K-PUR Corrosivity category/corrosion protection: C1: i.a. DIN EN ISO 12944-2 coating thickness lacquer/paint layer thickness [μm]: 60-80 Protection class/protection class: IP54 Design /mounting position: B3 Output torque/output torque [Nm]: 718.00 direction of rotation output direction of rotation: left/left Output shaft gearbox/output shaft [mm; inch]: V40x80 Transmission bearing/bearing: assigned bearing/ assigned bearings Oil type/Oil type: CLP 220 miner.Oil Oil quantity/Oil quantity [l]: 1.90 Shaft material/shaft material: C45 Sealing Gear/Sealing: Shaft Seal (WDR)/shaft seal ring Electrical design /electrical design: CE Number of pins/poles: 4 Rated frequency/nominal frequency [Hz]: 50 Rated voltage/nominal voltage [V]: 230/400 Circuit/Wiring: S100 (D/Y) Rated power/ nominal power [kW]: 0.75 Name engine speed/motor speed nom. [1/rpm]: 1440 Rated current/nominal current In [A]: 3.06/1.77 cosPHI/cosPHI: 0.76 KK location/terminal box position: 1A KK version/terminal box type: plastic/plastic Winding protection/motor protector: PTC Output shaft motor/output shaft [mm; inch]: V12x18.5 Engine sealing /sealing motor: normal/normal Isolation class /insulation class: F Efficiency class /efficiency class: IE3 active. ETA to 100%/Efficiency ETA to 100%: 82.5 active. ETA to 75% in%/Efficiency ETA to 75 in%: 81.8 active. ETA to 50%/Efficiency ETA to 50%: 78.1 Operating Mode/ Duty Type: S1 Fan /fan: plastic/plastic |
| Weight | 70 |
Please contact us to request a price quote for HIMMEL - D60-A80ICL4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy D60-A80ICL4 by HIMMEL in United Kingdom?
You can purchase D60-A80ICL4 by HIMMEL from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the D60-A80ICL4?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in United Kingdom?
While we are not the official distributor or seller of HIMMEL in United Kingdom, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access D60-A80ICL4 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for D60-A80ICL4 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for D60-A80ICL4?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
