IAI - NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2

Manufacturer IAI
Part Number NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2
Inner Code 4817243
Description Slider‑type electric actuator
Custom Code 8479500000
Technical specification
Actuator typeNS Series large‑nut rotation slider‑type electric actuator (single‑axis)
Drive systemØ 20 mm rolled C5 ball screw
Motor / Encoder400 W AC‑servo motor, incremental or absolute encoder (16 384 pulses / rev)
Stroke range2 300 – 3 000 mm (100 mm increments)
Leads available40 mm (speed‑oriented) or 20 mm (load‑oriented)
Max. horizontal load40 kg (40 mm lead) / 80 kg (20 mm lead)
Max. speed2 400 mm/s (40 mm lead) / 1 300 mm/s (20 mm lead)
Rated thrust170 N (40 mm lead) / 340 N (20 mm lead)
Repeatability± 0.01 mm
Allowable static momentMa 374 N·m, Mb 533 N·m, Mc 884 N·m
Mounting orientationHorizontal use only (not rated for vertical)
Ambient conditions0 – 40 °C, ≤ 85 % RH (non‑condensing)
Compliance / protectionCE‑marked, RoHS‑compliant; protection grade not specified
Compatible controllersRCON, RSEL, SCON‑CB/CGB, SSEL‑CS, XSEL series (various network options)
Weight 20.1

Please contact us to request a price quote for IAI - NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2 by IAI in United Kingdom?

You can purchase NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2 by IAI from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of IAI in United Kingdom?

While we are not the official distributor or seller of IAI in United Kingdom, we source our products from reliable channels and offer you original IAI equipment at competitive prices.

How can I access NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for NS-LXMXSA-A-400-40-2900-T2-X20-AQ-ET2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
