Ifm - OG5130
| Manufacturer | Ifm |
|---|---|
| Part Number | OG5130 |
| Inner Code | 1119982 |
| Description | Diffuse reflection sensor with background suppression |
| Custom Code | 85365019 |
| Technical specification | OGH-CPKG/US/90°/70MM Product characteristics Type of light red light Housing threaded type Application Special feature Background suppression Function principle Diffuse reflection sensor Electrical data Operating voltage [V] 10...30 DC; ("supply class 2" to cULus) Current consumption [mA] 25 Protection class II Reverse polarity protection yes Type of light red light Wave length [nm] 625 Outputs Electrical design PNP Output function complementary Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 200 Switching frequency DC [Hz] 1000 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes Detection zone Range [mm] < 70; (white paper 200 x 200 mm 90% remission) Range adjustable no Max. light spot diameter [mm] 16 Light spot dimensions refer to at maximum range Background suppression available yes Operating conditions Ambient temperature [°C] -25...60 Protection IP 68 |
| Weight | 0.058 |
Please contact us to request a price quote for Ifm - OG5130, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy OG5130 by Ifm in United Kingdom?
You can purchase OG5130 by Ifm from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the OG5130?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ifm in United Kingdom?
While we are not the official distributor or seller of Ifm in United Kingdom, we source our products from reliable channels and offer you original Ifm equipment at competitive prices.
How can I access OG5130 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for OG5130 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for OG5130?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
