Ifm - PC3553
| Manufacturer | Ifm |
|---|---|
| Part Number | PC3553 |
| Inner Code | 1120019 |
| Description | Pressure transmitter |
| Custom Code | 90262020 |
| Technical specification | Elektronischer Drucksensor; Steckverbindung Product characteristics Number of inputs and outputs Number of analogue outputs: 1 Measuring range [bar] 0...16 Process connection threaded connection G 1/4 external thread Application Application for industrial applications Media liquids and gases Medium temperature [°C] -25...90 Min. bursting pressure [bar] 600 Pressure rating [bar] 60 Type of pressure relative pressure Electrical data Operating voltage [V] 8.5...36 DC Min. insulation resistance [MΩ] 100; (500 V DC) Protection class III Reverse polarity protection yes Inputs / outputs Number of inputs and outputs Number of analogue outputs: 1 Outputs Total number of outputs 1 Output signal analogue signal Number of analogue outputs 1 Analogue current output [mA] 4...20 Max. load [Ω] 775; (Ub = 24 V; (Ub - 8,5 V) / 20 mA) Measuring/setting range Measuring range [bar] 0...16 Accuracy / deviations Repeatability [% of the span] < ± 0,15; (with temperature fluctuations < 10 K) Characteristics deviation [% of the span] < ± 2,5; (incl. drift when overtightened, zero point and span error) Linearity deviation [% of the span] < ± 0,25 (BFSL) / < ± 0,5 (LS) Hysteresis deviation [% of the span] < ± 0,25 Long-term stability [% of the span] < ± 0,1; (per 6 months) Temperature coefficient zero point [% of the span / 10 K] < ± 0,15; (-25...90 °C) Temperature coefficient span [% of the span / 10 K] < ± 0,2; (-25...90 °C) |
| Weight | 0.218 |
Please contact us to request a price quote for Ifm - PC3553, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PC3553 by Ifm in United Kingdom?
You can purchase PC3553 by Ifm from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PC3553?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ifm in United Kingdom?
While we are not the official distributor or seller of Ifm in United Kingdom, we source our products from reliable channels and offer you original Ifm equipment at competitive prices.
How can I access PC3553 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PC3553 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PC3553?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
