Ifm - N95004
| Manufacturer | Ifm |
|---|---|
| Part Number | N95004 |
| Inner Code | 1119885 |
| Description | Induktiver NAMUR-Sensor |
| Technical specification | I9-2003-N/M10X1/0,5M, Origin: DEUTSCHLAND, Custom Tariff No. 85365080, Weight in KG: 0,025 Product characteristics Electrical design NAMUR Output function normally closed Housing threaded type Dimensions [mm] M10 x 1 / L = 33 Application Application housing suited for an ambient pressure of max. 100 bar Installation installation on aluminium measuring wheel; (DN80) Pressure rating [bar] 100 Electrical data Connection to switching amplifiers yes Switching amplifiers connection to certified intrinsically safe circuits with the max. values: U = 15 V / I = 50 mA / P = 120 mW Nominal voltage DC [V] 8.2; (1kΩ) Supply voltage DC [V] 7.5...30 Current consumption [mA] < 1; (disabled; conductive: > 2,1) Protection class III Outputs Electrical design NAMUR Output function normally closed Permanent current rating of switching output DC [mA] 30 Switching frequency DC [Hz] 2000 Notes on switching frequency [Hz] on the aluminium measuring wheel Accuracy / deviations Hysteresis [% of Sr] 1...15 Operating conditions Ambient temperature [°C] -20...60 Protection IP 67 Tests / approvals EMC EN 60947-5-6 Shock/vibration resistance 30 g (11 ms) / 10-55 Hz (1 mm) Safety classification Max. internal capacitance [nF] 90 Max. internal inductance [µH] 100 |
| Weight | 1 |
Please contact us to request a price quote for Ifm - N95004, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
