Ifm - PC3542
| Manufacturer | Ifm |
|---|---|
| Part Number | PC3542 |
| Inner Code | 1120017 |
| Description | Pressure transmitter |
| Technical specification | PT-100-SBG14-A-ZVG/US/ /W, Origin: DEUTSCHLAND, Custom Tariff No. 90262020, Weight in KG: 0,079 Product characteristics Number of inputs and outputs Number of analog outputs: 1 Measuring range [bar] 0...100 Process connection threaded connection G 1/4 external thread Application Application for industrial applications Media liquids and gases Medium temperature [°C] -25...90 Min. bursting pressure [bar] 1000 Pressure rating [bar] 200 Type of pressure relative pressure Electrical data Operating voltage [V] 8.5...36 DC Min. insulation resistance [MΩ] 100; (500 V DC) Protection class III Reverse polarity protection yes Inputs / outputs Number of inputs and outputs Number of analog outputs: 1 Outputs Total number of outputs 1 Output signal analog signal Number of analog outputs 1 Analog current output [mA] 4...20 Max. load [Ω] 775; (Ub = 24 V; (Ub - 8,5 V) / 20 mA) Measuring/setting range Measuring range [bar] 0...100 Accuracy / deviations Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K) Characteristics deviation [% of the span] < ± 1,0; (incl. drift due to tightening torque, zero and span error) Linearity deviation [% of the span] < ± 0,25 (BFSL) / < ± 0,5 (LS) Hysteresis deviation [% of the span] < ± 0,2 Long-term stability [% of the span] < ± 0,1; (per 6 months) Temperature coefficient zero point [% of the span / 10 K] < ± 0,1; (-25...90 °C) Temperature coefficient span [% of the span / 10 K] < ± 0,1; (-25...90 °C) |
| Weight | 1 |
Please contact us to request a price quote for Ifm - PC3542, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
