Indexator - 8400009 / XR400 I
| Manufacturer | Indexator |
|---|---|
| Part Number | 8400009 / XR400 I |
| Inner Code | 4458731 |
| Custom Code | 84122981 |
| Technical specification | INDEXATOR Rotator XR 400-I ⦁ Compact rotator with large slewing ring bearing ⦁ External force transfer via the robust housing ⦁ Inwardly floating vane motor, This makes it particularly durable ⦁ Suitable for oscillating suspension and fixed mounting on the excavator ⦁ Top mount suitable for Indexator headstock with 80 mm bolt and 275 mm pendulum width (item no. 8000775) ⦁ For extreme applications with particularly high requisitions ⦁ Extremely high torques ⦁ Suitable for reciprocating material handling machines Suspension 25 - 45 t net weight, excavator with Two-shell gripper up to 2.5 m³ and multi-shell gripper up to 1.2 m³.55,000 kg max. static load, 20,000 kg max. dynamic load, 14,000 kg max radial load ⦁ Torque of 4,100 Nm at 250 bar ⦁ Oil requirement 35 l/min ⦁ Weight 180 kg ⦁ Top mount: flange with blind holes and Thread (bolt circle 12xM20-240 mm) ⦁ Bottom mount: 450 mm diameter bolt circle (30x14-450mm) ⦁ Top hydraulic connections 2 x G 1" + 2 x G 1/2" ⦁ Bottom hydraulic connections 2 x G 1" Areas of application: ⦁ Use on reciprocating material handling machines Suspension 30 - 50 t operating weight ⦁ Excavator with two-shell gripper up to 2.5 m³ ⦁ Excavator with multi-shell gripper up to 1.2 m³ ⦁ Excavator with wood, multifunctional or sorting grabber in Fixed installation up to 27 t operating weight |
| Weight | 180 |
