Ingun - HFS-821 313 050A18005USBMINI-D/ HFS-821-0029
| Manufacturer | Ingun |
|---|---|
| Part Number | HFS-821 313 050A18005USBMINI-D/ HFS-821-0029 |
| Inner Code | 5104061 |
| Description | high frequency pen |
| Technical specification | general data Product group: HFS high frequency contact pins Series: HFS-821 Subseries: HFS-821 pitch: 12.5 mm Test sample/contact: USB MINI type B/AB; HS Autolink 1 Installation type: flange Gender test sample: F signal conductor female/socket Floating storage: yes Anti-twist: yes Continuous piston: yes Interface suitable assembly: SE-821 USB-MINI plug 5-pin screwed for HFS-821/USB-MINI Gender suitable assembly: M signal conductor male/plug Recommended torque at the interface: 10 cNm Min. temperature: - 40 °C Max. temperature: + 80 °C RoHS compliant: RoHS-3; 6c External conductor data Outer conductor head shape: 05 Round (full radius) Outer conductor head diameter: 9 mm Total spring force of outer conductor at working stroke: 18 N Outer conductor working stroke: 3.5 mm Maximum stroke of outer conductor: 5 mm Replaceable outer conductor: no Signal conductor data Signal conductor head shape: 13 tip 30°, rounded Signal conductor head diameter: 0.5 mm Signal conductor head shape Material: 3 CuBe Head shape signal conductor surface: A gold Number of signal conductors: 5 Replaceable signal conductor: no Maximum current carrying capacity of signal conductors: 3 A Electrical data Impedance: 100 ohms Mechanical data Total spring force at working stroke: 18 N total length: 49 mm Pin case diameter: 11 mm Installation height without contact socket: 27 mm |
| Weight | 0.006 |
Please contact us to request a price quote for Ingun - HFS-821 313 050A18005USBMINI-D/ HFS-821-0029, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy HFS-821 313 050A18005USBMINI-D/ HFS-821-0029 by Ingun in United Kingdom?
You can purchase HFS-821 313 050A18005USBMINI-D/ HFS-821-0029 by Ingun from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the HFS-821 313 050A18005USBMINI-D/ HFS-821-0029?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ingun in United Kingdom?
While we are not the official distributor or seller of Ingun in United Kingdom, we source our products from reliable channels and offer you original Ingun equipment at competitive prices.
How can I access HFS-821 313 050A18005USBMINI-D/ HFS-821-0029 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for HFS-821 313 050A18005USBMINI-D/ HFS-821-0029 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for HFS-821 313 050A18005USBMINI-D/ HFS-821-0029?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
