INKOMA - HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24
| Manufacturer | INKOMA |
|---|---|
| Part Number | HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24 |
| Inner Code | 4809543 |
| Description | high performance screw jacks |
| Technical specification | Article 129284 with HSGK cooling fins Size 4 - max. static lifting force transmission 50 kN dynamic load rating ball screw drive Cdyn=41.4 kN upright version with SVA anti-twist and anti-twist protection for 200 mm useful stroke Reduction N, i= 7:1 - stroke per revolution of the drive shaft 3.4 mm with drive shaft on both sides A and B Spindle side HF cover design: high with guide ring and for disc bellows connection Cover design Thermowell side HFS: High with guide ring and for thermowell connection E1E mounting surface Gearbox with oil lubrication, Klübersynth GH-6-220, with oil sight glass O Including ball screw KGS 40x24, spindle length size Z = 311 mm (Dimension Z from the top of the housing to the end of the spindle) with thermowell for 200 mm useful stroke, L = 338 mm, prepared for 2x limit switch mounting, including adjusting rings installation position vertical standing, pressure load |
| Weight | 40 |
Please contact us to request a price quote for INKOMA - HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24 by INKOMA in United Kingdom?
You can purchase HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24 by INKOMA from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of INKOMA in United Kingdom?
While we are not the official distributor or seller of INKOMA in United Kingdom, we source our products from reliable channels and offer you original INKOMA equipment at competitive prices.
How can I access HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for HSGK-4-SVA-200-N-AB-HF-HFS-E1E-0-KGS 40x24?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
