INKOMA - KSH-2-SVA-150-2:1-KB-C-KGS-32X20
| Manufacturer | INKOMA |
|---|---|
| Part Number | KSH-2-SVA-150-2:1-KB-C-KGS-32X20 |
| Inner Code | 4696152 |
| Description | GEARBOX |
| Custom Code | 84834023 |
| Technical specification | 139150/KSH-2-SVA- 150-2:1 -KB-C-KGS 32x20 High-speed bevel gearbox, standing spindle with anti-twist protection with anti-twist protection Bevel gear on side B Transmission with oil lubrication (oil sight glass, vent & plug screw on side D) Useful stroke = 150 mm incl. ball screw KGS 32x20, mat. steel dyne. Load rating = 29.7 kN Dimension Z = 234 mm (Z dimension from top edge of housing to spindle end) incl. square protection tube, mat. steel Dimension L = 270 mm incl. mounting flange BF-3, Mat. steel incl. disc bellows SB-KSH-2 Lmin = 30mm Lmax = 180 mm Cuff 1 = Ø46 x 10 mm Cuff 2 = Ø60 x 15 mm incl. clamps and air screens Installation position: vertical-standing, pressure load |
| Weight | 40 |
Please contact us to request a price quote for INKOMA - KSH-2-SVA-150-2:1-KB-C-KGS-32X20, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
