Johnson Controls - VA7830-GGA-11
| Manufacturer | Johnson Controls |
|---|---|
| Part Number | VA7830-GGA-11 |
| Inner Code | 4961781 |
| Technical specification | specifications Operating voltage: 24 V AC, 50/60 Hz power consumption: 11 VA Effective power: 8 W at 3 s/mm, 6 W at 6 s/mm Input impedance: 0 (2)... 10 V: min. 100 kΩ /0 (4)... 20 mA: min. 120 Ω Control: continuous: 0 (2)... 10 V DC or 0 (4)... 20 mA Feedback: 2 mA max at 0 (2) V DC to 10 V DC, input impedance min 5 kΩ Positioning force: 1000 N +30/-20% max. stroke: 8 to 25 mm Runtime: selectable: 6 s/mm ± 10% or 3 s/mm ± 10% Behavior in case of power failure: spindle moves out Spring return time in case of power failure: 1.4 s/mm Operating conditions: ‐5 °C to +55 °C, 10 to 90% RH condensing material Gearbox, bracket: Die-cast aluminum Housing: resin ABS/PC, self-extinguishing according to UL94 V-0 Spindle: stainless steel Coupling: brass |
| Weight | 3.5 |
Please contact us to request a price quote for Johnson Controls - VA7830-GGA-11, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy VA7830-GGA-11 by Johnson Controls in United Kingdom?
You can purchase VA7830-GGA-11 by Johnson Controls from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the VA7830-GGA-11?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Johnson Controls in United Kingdom?
While we are not the official distributor or seller of Johnson Controls in United Kingdom, we source our products from reliable channels and offer you original Johnson Controls equipment at competitive prices.
How can I access VA7830-GGA-11 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for VA7830-GGA-11 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for VA7830-GGA-11?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
